INSTALLER: THIS MANUAL MUST BE LEFT WITH THE APPLIANCE.
CONSUMER: KEEP THIS MANUAL FOR FUTURE REFERENCE.
Improper installation, adjustment, alteration, service, or maintenance can cause
severe injury or death and may result in property damage. Read these installation,
operating and maintenance instructions thoroughly before installing or servicing this
equipment.
Do not store or use gasoline or other flammable vapors or liquids in or
near this or any other appliance.
An LP (Liquefied Petroleum) tank that is not connected for use shall not
be stored in or near this or any other appliance.
If you smell gas:
FIRE PIT INSTALLATION
AND OPERATING INSTRUCTIONS
FOR MODELS 401641FP, SL30RFP, SB30RFP
WARNING
DANGER
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, keep away from appliance and immediately
call gas supplier and fire department.
WARNING
For Outdoor Use Only !
WARNING
Advertisement
Table of Contents
Related Manuals for tropitone 401641FP
Summary of Contents for tropitone 401641FP
- Page 1 FIRE PIT INSTALLATION AND OPERATING INSTRUCTIONS FOR MODELS 401641FP, SL30RFP, SB30RFP INSTALLER: THIS MANUAL MUST BE LEFT WITH THE APPLIANCE. CONSUMER: KEEP THIS MANUAL FOR FUTURE REFERENCE. WARNING Improper installation, adjustment, alteration, service, or maintenance can cause severe injury or death and may result in property damage.
- Page 2 ...
-
Page 3: Installation
WARNING Tropitone recommends that all gas products installed in the USA and CANADA be serviced and maintained by professionals that are certified by the National Fireplace Institute (NFI) as NFI Gas Specialist or by the Wood Energy Technical Training (WETT). - Page 4 IMPORTANT It is recommended that material such as granite, marble or other dense stone be kept away from heat and flame due to the risk of cracking. Tropitone will not be held responsible for materials damaged due to excessive heat.
- Page 5 DANGER Do not install this product under any type of covering, including overhangs, patio covers, umbrellas, cabanas, tree limbs or branches. The risk of fire, inhalation of fumes, and exposure to excessive heat increases greatly if this product is installed under any type of covering, which could result in personal injury, damage to property or death.
- Page 6 WARNING: The LP Gas tank or cylinder used must comply with the following requirements. Use of other tanks or cylinders which do not meet these requirements may create an unsafe condition which could cause injury or death to you, or damage to your personal property, including the risk of fire or explosion.
- Page 7 WARNING : Inspect the hose and tank connector before each use to insure there is no damage caused by rodents, weather or other conditions. NEVER use any Fire Pit which has any components, including the gas hose or gas tank connector damaged in any way. If you find any damage, turn off the valve on the gas tank and call a licensed repair technician to replace damaged components.
-
Page 8: Fire Media Installation
FIRE MEDIA INSTALLATION Please follow the instructions below to add the finishing touch to your Fire Pit. Your Fire Pit needs a fire media in order to get the proper flame characteristics from the burner assembly. The media can be lava rocks, decorative fire glass, fire logs, or other fire media specifically designed for outdoor fire pits and fireplaces. -
Page 9: Lighting Instructions
LIGHTING INSTRUCTIONS To light your new Fire Pit, complete all installation and safety instructions above. Gas Valve Knob Gas Tank Gas Valve 1. Make sure the gas valve on the gas tank is open (turned all the way to the left). ... -
Page 10: Internal Controls
INTERNAL CONTROLS (401600RD BASE) PARTS LIST Item No. Description Part No. Knob, Black, for Gas Valve R01MS102 Nut, Retaining, M1 for Gas Valve R02NU501 Gas Valve R18VL100 3/8” Flare x 3/8” MIPT R18CO108 Gas Hose with Regulator, 3/8” x 12” Long R18FH100 Gas Plumbing Support Weldment WSL30RFPGVS... - Page 11 BURNER TRAY AND CONTROLS (401600RD BASE) PARTS LIST Item No. Description Part No. Burner Tray, Round 12” R15MS306 Burner Tray, Square 12” (not shown) R15MS307 Blow Out Box Assembly R19NT107 6” Stamped Burner M18BA109 Nut, 1/2" Stainless Steel R02NU500 Pilot & Thermocouple Assembly R19TC100 Washer, 1.500 OD x .890 ID x .090 R02WA880...
- Page 12 FIRE PIT NATURAL GAS CONVERSION AND OPERATING INSTRUCTIONS First turn the LP Gas tank (if installed) fully off by rotating the valve completely to the left until closed. Then disconnect the LP Gas tank hose with built in regulator by turning the large connector fully counter-clockwise until the hose is completely disconnected.
- Page 13 CAUTION: Use a joint compound or thread tape approved for the type of gas this appliance is intended to use on all male threads EXCEPT compression threads. Never apply thread tape of compound to compression threads. Beneath the Burner tray, locate the Gas/Air Mixer in the plumbing. Remove the LP Gas/Air Mixer and replace with the Natural Gas Orifice.
- Page 14 Once your Fire Pit has been converted to Natural Gas, please locate the small silver label and remove the bottom strip. Place this strip over the section indicated above, on the large label located on the inside door. R9T15FIRE Page 14 of 16 Rev.
- Page 15 R9T15FIRE Page 15 of 16 Rev. A 29SEP15 ...
- Page 16 This Fire Pit has been tested and approved in accordance with ANSI Z21.97 by ICC-ES Listing No. PMG-1114 Tropitone Furniture Co., Inc. 5 Marconi Irvine, Ca 92618 949-951-2010 www.tropitone.com 1401 Commerce Blvd. Sarasota, Fl 34243 © Tropitone Furniture Co., Inc, 2015 R9T15FIRE Page 16 of 16 Rev. A 29SEP15 ...
