401400RD MODELS: 401442FP, 401554FP, 801486FP, 801554FP, 821486FP, 821549FP
401400SQ MODELS: 401443FP, 401467FP, 401558FP 401700RCT MODELS: 401767FP-24,
801753FP-24, 821753FP-24, SB5442FP-24, SL5442FP-24 401800SQ MODELS: CM42SFP-18,
CM42SFP-25 401800RCT MODELS: CM5030FP-18, CM5030FP-25
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Do not store or use gasoline, or other flammable vapors and liquids, in
the vicinity of this or any other appliance.
An LP-cylinder (Liquefied Petroleum) not connected for use shall not be
stored in the vicinity of this or any other appliance.
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion,
which could cause property damage, personal injury, or death.
Installation and service must be performed by a qualified installer, service
DANGER
WARNING:
explosion may result causing property damage, personal injury, or loss of life.
FIRE PIT INSTALLATION
AND OPERATING INSTRUCTIONS
WARNING
DANGER
FIRE OR EXPLOSION HAZARD
WARNING: For Outdoor Use Only.
agency, or the gas supplier.
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as camper, tent, car, or home.
If the information in this manual is not followed exactly, a fire or
CARBON MONOXIDE HAZARD
Advertisement
Related Manuals for tropitone 401800SQ Series
Summary of Contents for tropitone 401800SQ Series
- Page 1 FIRE PIT INSTALLATION AND OPERATING INSTRUCTIONS 401400RD MODELS: 401442FP, 401554FP, 801486FP, 801554FP, 821486FP, 821549FP 401400SQ MODELS: 401443FP, 401467FP, 401558FP 401700RCT MODELS: 401767FP-24, 801753FP-24, 821753FP-24, SB5442FP-24, SL5442FP-24 401800SQ MODELS: CM42SFP-18, CM42SFP-25 401800RCT MODELS: CM5030FP-18, CM5030FP-25 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
-
Page 2: Installation
WARNING Tropitone recommends that all gas products installed in the USA and CANADA be serviced and maintained by professionals that are certified by the National Fireplace Institute (NFI) as NFI Gas Specialist or by the Wood Energy Technical Training (WETT). - Page 3 IMPORTANT It is recommended that material such as granite, marble or other dense stone be kept away from heat and flame due to the risk of cracking. Tropitone will not be held responsible for materials damaged due to excessive hea...
- Page 4 DANGER Do not install this product under any type of covering, including overhangs, patio covers, umbrellas, cabanas, tree limbs or branches. The risk of fire, inhalation of fumes, and exposure to excessive heat increases greatly if this product is installed under any type of covering, which could result in personal injury, damage to property or death.
- Page 5 WARNING: The LP Gas tank or cylinder used must comply with the following requirements. Use of other tanks or cylinders which do not meet these requirements may create an unsafe condition which could cause injury or death to you, or damage to your personal property, including the risk of fire or explosion.
- Page 6 9 volt battery located in a Battery Case under the 9V Ignition Power Supply. The 9 volt battery, which is installed in Tropitone Fire Pits, is shipped with a battery terminal cover which must be removed prior Battery Case of to the first use of the Fire Pit.
- Page 7 Incorrect media OPENING! installation will cause the pilot flame to suffocate and turn off pit or delay main burner ignition. Lava rock not available from Tropitone. R9T12FIRE Page 7 of 16 Rev. L 08FEB19...
-
Page 8: Lighting Instructions
LIGHTING INSTRUCTIONS To light your new Fire Pit, complete all installation and safety instructions above. Be sure to install a 9 volt battery in the ignition system battery case mounted on the inside post of the right door frame. To install the battery, follow the instructions on page 6. Spark Igniter Gas Valve Switch... -
Page 9: Internal Controls
INTERNAL CONTROLS (401400RD, 401400SQ, 401700RCT, 401800SQ, & 401800RCT BASE) PARTS LIST Item No. Description Part No. Ignition Switch With Gasket R19SW100 Gas Valve R18VL100 Nut, Retaining, M1 for Gas Valve R02NU501 Knob, Black, for Gas Valve R02MS102 Gas Flex Line, 24” x 1/2" R15SP100 Nipple, 3/8”... - Page 10 BURNER TRAY AND CONTROLS (401400RD, 401400SQ, & 401800SQ BASE) PARTS LIST Item No. Description Part No. Burner, Spun, 12” Diameter STMPBA12 Blow Out Box Assembly R19NT108 Pilot & Thermocouple Assembly R19TC101 R19TC100 Electrical Insulation, Silicone/Fiberglass R19NS100 Burner Tray, Square 18” (not shown) Igniter Assembly R19NT100 Nut, 1/2”...
- Page 11 BURNER TRAY AND CONTROLS (401700RCT & 401800RCT BASES) PARTS LIST Item No. Description Part No. Rectangular Stamped Burner STMPBA243 Spacer M401767FPS Electrical Insulation, Silicone/Fiberglass R19NS100 Blow Out Box Assembly R19NT108 Pilot & Thermocouple Assembly R19TC101 Igniter Assembly R19NT100 Burner Support R15MS309 Burner Tray, 30”...
- Page 12 FIRE PIT NATURAL GAS CONVERSION AND OPERATING INSTRUCTIONS First turn the LP Gas tank (if installed) fully off by rotating the valve completely to the left until closed. Then disconnect the LP Gas tank hose with built in regulator (shown in blue) by turning the large connector (shown in black) fully counter-clockwise until the hose is completely disconnected.
- Page 13 CAUTION: Use a joint compound or thread tape approved for the type of gas this appliance is intended to use on all male threads EXCEPT compression threads. Never apply thread tape of compound to compression threads. Beneath the Burner tray, locate the Gas/Air Mixer in the plumbing. Remove the LP Gas/Air Mixer and replace with the Natural Gas Orifice.
- Page 14 Once your Fire Pit has been converted to Natural Gas, please locate the small silver label and remove the bottom strip. Place this strip over the section indicated above, on the large label located on the inside door. R9T12FIRE Page 14 of 16 Rev.
- Page 15 This page intentially left blank. R9T12FIRE Page 15 of 16 Rev. L 08FEB19...
- Page 16 This Fire Pit has been tested and approved in accordance with ANSI Z21.97 by ICC-ES Listing No. PMG-1114 Tropitone Furniture Co., Inc. 5 Marconi Irvine, Ca 92618 949-951-2010 www.tropitone.com 1401 Commerce Blvd. Sarasota, Fl 34243 © Tropitone Furniture Co., Inc, 2019 R9T12FIRE Page 16 of 16 Rev. L 08FEB19...
