401901RD MODELS: 401942FPL-18, 801942FPL-18, 821942FPL-18, TX1942FPL-18,
TX1942FPL-25 401901RCT MODELS: TX1953FPL-18, TX1953FPL-25
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Do not store or use gasoline, or other flammable vapors and liquids, in
the vicinity of this or any other appliance.
An LP-cylinder (Liquefied Petroleum) not connected for use shall not be
stored in the vicinity of this or any other appliance.
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion,
which could cause property damage, personal injury, or death.
Installation and service must be performed by a qualified installer, service
DANGER
WARNING:
explosion may result causing property damage, personal injury, or loss of life.
FIRE PIT INSTALLATION
AND OPERATING INSTRUCTIONS
WARNING
DANGER
FIRE OR EXPLOSION HAZARD
WARNING: For Outdoor Use Only.
agency, or the gas supplier.
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as camper, tent, car, or home.
If the information in this manual is not followed exactly, a fire or
CARBON MONOXIDE HAZARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 401901RD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for tropitone 401901RD

  • Page 1 FIRE PIT INSTALLATION AND OPERATING INSTRUCTIONS 401901RD MODELS: 401942FPL-18, 801942FPL-18, 821942FPL-18, TX1942FPL-18, TX1942FPL-25 401901RCT MODELS: TX1953FPL-18, TX1953FPL-25 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNING Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity of this or any other appliance.
  • Page 2: Installation

    WARNING Tropitone recommends that all gas products installed in the USA and CANADA be serviced and maintained by professionals that are certified by the National Fireplace Institute (NFI) as NFI Gas Specialist or by the Wood Energy Technical Training (WETT).
  • Page 3 IMPORTANT It is recommended that material such as granite, marble or other dense stone be kept away from heat and flame due to the risk of cracking. Tropitone will not be held responsible for materials damaged due to excessive heat.
  • Page 4 DANGER Do not install this product under any type of covering, including overhangs, patio covers, umbrellas, cabanas, tree limbs or branches. The risk of fire, inhalation of fumes, and exposure to excessive heat increases greatly if this product is installed under any type of covering, which could result in personal injury, damage to property or death.
  • Page 5 For 25” height bases, place the LP gas tank in the tank retaining ring. DANGER 401901RD Do not use a vertical LP gas tank in place of a horizontal LP gas tank in and 401901RCT base models that are 18” tall.
  • Page 6 WARNING Inspect the hose and tank connector before each use to insure there is no damage caused by rodents, weather or other conditions. NEVER use any Fire Pit which has any components, including the gas hose or gas tank connector damaged in any way. If you find any damage, turn off the valve on the gas tank and call a licensed repair technician to replace damaged components.
  • Page 7 FLAME GUARD INSTALLATION Please follow the instructions below if you have a Matrix top fire pit. The model numbers for these fire pits are TX1942FPL-18, TX1953FPL-18, TX1924FPL-25, TX1953FPL-25. WARNING: Do not try to lift or flip components with only one person. Components may be heavy and awkward to handle, and may result in injury to persons or damage to property if not lifted properly.
  • Page 8: Fire Media Installation

    2) Apply decorative glass or fire pebbles just cover ring and pan- no more than ½” above deep enough to cover bottom of pan. the burner. Lava rock not available from Tropitone. R9T18FIRE Page 8 of 16 Rev. B 03JUN20...
  • Page 9: Lighting Instructions

    LIGHTING INSTRUCTIONS To light your new Fire Pit, complete all installation and safety instructions above. Gas Valve Knob Gas Tank Gas Valve 1. Gas valve knob should be in off position. 2. Make sure the gas valve on the gas tank is open (turned all the way to the left). 3.
  • Page 10: Internal Controls

    INTERNAL CONTROLS (401901RD & 401901RCT BASE) PARTS LIST Item No. Description Part No. Gas Valve R18VL108 Gas Plumbing Support Weldment W401942FPSGV Gas Plumbing Support Weldment WTX1953FPSGV 1/2” x 1/2” FIP 90 R15CO101 Gas Flex Line, 24” x 1/2" R15SP100 Knob, Black, for Gas Valve...
  • Page 11 BURNER TRAY AND CONTROLS (401901RD BASE) PARTS LIST Item No. Description Part No. Burner, Spun, 12” Diameter STMPBA12 Cover Plate R15MS343 Nut, 1/2” Stainless Steel R02NU500 Burner Tray, Round 18” R15MS300 Washer, 1.50” OD x 0.0890 ID x 0.09 R02WA880 Nipple, 1/2”...
  • Page 12 BURNER TRAY AND CONTROLS (401700RCT & 401800RCT BASES) PARTS LIST Item No. Description Part No. Rectangular Stamped Burner STMPBA243 Cover Plate R15MS343 Spacer M401767FPS Burner Support R15MS309 Burner Tray, 30” x 8” Rectangular R15MS308 Washer, 1” Stainless Steel R02WA880 Nipple, 1/2” Stainless Steel R15CO106 Elbow, 1/2"...
  • Page 13 FIRE PIT NATURAL GAS CONVERSION AND OPERATING INSTRUCTIONS First turn the LP Gas tank (if installed) fully off by rotating the valve completely to the right until closed. Then disconnect the LP Gas tank hose with built in regulator (shown in blue) by turning the large connector (shown in black) fully counter-clockwise until the hose is completely disconnected.
  • Page 14 CAUTION: Use a joint compound or thread tape approved for the type of gas this appliance is intended to use on all male threads EXCEPT compression threads. Never apply thread tape of compound to compression threads. Beneath the Burner tray, locate the Gas/Air Mixer in the plumbing. Remove the LP Gas/Air Mixer and replace with the Natural Gas Orifice.
  • Page 15 Once your Fire Pit has been converted to Natural Gas, please locate the small silver label and remove the bottom strip. Place this strip over the section indicated above, on the large label located on the inside door. R9T18FIRE Page 15 of 16 Rev.
  • Page 16 Tropitone Furniture Co., Inc. 5 Marconi Irvine, Ca 92618 949-951-2010 www.tropitone.com 1401 Commerce Blvd. Sarasota, Fl 34243 © Tropitone Furniture Co., Inc, 2020 R9T18FIRE Page 16 of 16 Rev. B 03JUN20...
