FOR MODELS 401100, 401154FP, 401158FP, 800154FP, 820649FP,
401442FP, 401443FP, 401467FP, 801486FP, 821486FP, BE42RFP,
INSTALLER: THIS MANUAL MUST BE LEFT WITH THE APPLIANCE.
CONSUMER: KEEP THIS MANUAL FOR FUTURE REFERENCE.
Improper installation, adjustment, alteration, service, or maintenance can cause
severe injury or death and may result in property damage. Read these installation,
operating and maintenance instructions thoroughly before installing or servicing this
equipment.
Do not store or use gasoline or other flammable vapors or liquids in or
near this or any other appliance.
An LP (Liquefied Petroleum) tank that is not connected for use shall not
be stored in or near this or any other appliance.
If you smell gas:
FIRE PIT INSTALLATION
AND OPERATING INSTRUCTIONS
BE42SFP, BE48RFP, BE48SFP, BE5442FP
WARNING
WARNING
DANGER
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, keep away from appliance and immediately
call gas supplier and fire department.
WARNING
For Outdoor Use Only !
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for tropitone S 401100
Summary of Contents for tropitone S 401100
- Page 1 FIRE PIT INSTALLATION AND OPERATING INSTRUCTIONS FOR MODELS 401100, 401154FP, 401158FP, 800154FP, 820649FP, 401442FP, 401443FP, 401467FP, 801486FP, 821486FP, BE42RFP, BE42SFP, BE48RFP, BE48SFP, BE5442FP INSTALLER: THIS MANUAL MUST BE LEFT WITH THE APPLIANCE. CONSUMER: KEEP THIS MANUAL FOR FUTURE REFERENCE. ...
-
Page 2: Installation
WARNING Tropitone recommends that all gas products installed in the USA and CANADA be serviced and maintained by professionals that are certified by the National Fireplace Institute (NFI) as NFI Gas Specialist or by the Wood Energy Technical Training (WETT). - Page 3 kept away from heat and flame due to the risk of cracking. Tropitone will not be held responsible for materials damaged due to excessive heat.
- Page 4 DANGER Do not install this product under any type of covering, including overhangs, patio covers, umbrellas, cabanas, tree limbs or branches. The risk of fire, inhalation of fumes, and exposure to excessive heat increases greatly if this product is installed under any type of covering, which could result in personal injury, damage to property or death.
- Page 5 WARNING: The LP Gas tank or cylinder used must comply with the following requirements. Use of other tanks or cylinders which do not meet these requirements may create an unsafe condition which could cause injury or death to you, or damage to your personal property, including the risk of fire or explosion.
- Page 6 9 volt battery located in the Spark Igniter Power supply. The 9 volt battery, which is installed in the Tropitone Fire Pits, is shipped with a battery terminal cover which must be removed prior to the first use of the Fire Pit.
-
Page 7: Fire Media Installation
FIRE MEDIA INSTALLATION Please follow the instructions below to add the finishing touch to your Fire Pit. Your Fire Pit needs a fire media in order to get the proper flame characteristics from the burner assembly. The media can be lava rocks, decorative fire glass, fire logs, or other fire media specifically designed for outdoor fire pits and fireplaces. -
Page 8: Lighting Instructions
LIGHTING INSTRUCTIONS To light your new Fire Pit, complete all installation and safety instructions above. Be sure to install a 9 volt battery in the ignition system battery case mounted on the inside post of the right door frame. To install the battery, follow the instructions on page 6. -
Page 9: Internal Controls
INTERNAL CONTROLS (401100 BASE) PARTS LIST Item No. Description Part No. Gas Flex Line, 24” x 1/2" R15SP100 1/2” x 1/2” FIP 90 R15CO101 Gas Hose with Regulator, 3/8” x 12” Long R18FH100 3/8”... - Page 10 BURNER TRAY AND CONTROLS (401100 BASE) ...
- Page 11 INTERNAL CONTROLS (401400RD & 401400SQ BASES) PARTS LIST Item No. Description Part No. Gas Flex Line, 24” x 1/2" R15SP100 1/2” x 1/2” FIP 90 R15CO101 Gas Hose with Regulator, 3/8” x 12” Long R18FH100 3/8”...
- Page 12 BURNER TRAY AND CONTROLS (401400RD & 401400SQ BASES) Pressure Test Port PARTS LIST Item No. Description Part No. Blow Out Box Assembly R19NT108 Burner, 6 Point Arm, 12” Diameter R18BA104 2 Nipple, 1/2” Stainless Steel R15CO106 Burner Tray, Round 18”...
- Page 13 FIRE PIT NATURAL GAS CONVERSION AND OPERATING INSTRUCTIONS First turn the LP Gas tank (if installed) fully off by rotating the valve completely to the left until closed. Then disconnect the LP Gas tank hose with built in regulator (shown in blue) by turning the large connector (shown in black) fully counter-clockwise until the hose is completely disconnected.
- Page 14 CAUTION: Use a joint compound or thread tape approved for the type of gas this appliance is intended to use on all male threads EXCEPT compression threads. Never apply thread tape of compound to compression threads. Beneath the Burner tray, locate the Gas/Air Mixer in the plumbing. Remove the LP Gas/Air Mixer and replace with the Natural Gas Orifice.
- Page 15 Once your Fire Pit has been converted to Natural Gas, please locate the small silver label and remove the bottom strip. Place this strip over the section indicated above, on the large label located on the inside door. R9T12FIRE Page 15 of 16 Rev.
- Page 16 This Fire Pit has been tested and approved in accordance with ANSI Z21.97 by ICC-ES Listing No. PMG-1114 Tropitone Furniture Co., Inc. 5 Marconi Irvine, Ca 92618 949-951-2010 www.tropitone.com 1401 Commerce Blvd. Sarasota, Fl 34243 © Tropitone Furniture Co., Inc, 2014 R9T12FIRE Page 16 of 16 Rev. F 10SEP14 ...
