- Page 1 User Manual Stoltzen SHE70K HDBaseT Extender Set 70m, 4K All Rights Reserved Version: SHE70K_2016V1.0...
- Page 2 All product function is valid till 2016-7-21. Trademarks Product model, Stoltzen and its logo Stoltzen are trademarks of Stoltzen. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of Stoltzen.
- Page 3 Stoltzen SHE70K HDBaseT Extender Set SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
Stoltzen SHE70K HDBaseT Extender Set Contents 1. Introduction ......................... 1 1.1 Introduction to SHE70K ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Introduction of Product Appearance ................2 2.1 Appearance of SHE70T ..................2 2.2 Appearance of SHE70R ..................3 3. -
Page 5: Introduction
Note: Please use a CAT5e cable with low impedance (Shielded twisted pair will be better and should be well grounded for good transmission effect. 1.3 Package List 1 x SHE70K (including SHE70T and SHE70R) 4 x detachable mounting ears 4 x screws 8 x plastic cushions ... -
Page 6: Introduction Of Product Appearance
Stoltzen SHE70K HDBaseT Extender Set 2. Introduction of Product Appearance 2.1 Appearance of SHE70T HDMI IN: Connect to HDMI source. IR IN: Connect to an IR receiver, the IR signal received from this port can only send out via SHE70R. -
Page 7: Appearance Of She70R
IR OUT: Connect with IR emitter, the sent IR signals are received by SHE70T. Power Indicator: illuminate when power up TP IN: Connect to the HDBaseT port on the SHE70T via CAT5e/ CAT6 cable. Note: SHE70K boasts 2 indicators to show real-time operation information: Indicator Function... -
Page 8: System Connection
Stoltzen SHE70K HDBaseT Extender Set 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safety. -
Page 9: Application
Stoltzen SHE70K HDBaseT Extender Set 3.4 Application SHE70K has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. 3.5 Twisted Pair Cable Connection The Cat5e/Cat6 terminations for HDBaseT devices should be a straight thru TIA/EIAT568B standard. -
Page 10: Specification
Stoltzen SHE70K HDBaseT Extender Set 4. Specification Model SHE70T SHE70R Spec Input Input Signal 1 HDMI,1 IR 1 IR, 1 RJ-45 HDMI female 3.5mm mini jack Input Connector 3.5mm mini jack RJ-45 Video Signal HDMI1.4 HDMI1.4 Digital audio, transmit Digital audio, transmit... -
Page 11: Supported Resolution
480I, 480P, 576I, 576P, 720P, 1080I, 1080P, 4Kx2K, 1080P 3D 640x480@60Hz, 640x480@72Hz, 640x480@75Hz, 800x600@60Hz, 800x600@72Hz, 800x600@75Hz, 1024x768@60Hz, 1024x768@70Hz, 1024x768@75Hz, 1280x720@60 Hz, 1280x1024@60Hz, 1280x1024@75Hz, 1600x1200@60Hz, 1920x1080@60Hz, 1920x1200@60Hz. Note: SHE70K supports 4k&1080p 3D HDMI signal, please adopt quality HDMI cables compliant with HDMI1.4 for reliable transmission when using. -
Page 12: Panel Drawing
Stoltzen SHE70K HDBaseT Extender Set 5. Panel Drawing 61.60 mm LINK HDCP DC 12V TP OUT HDMI IN IR IN IR OUT 5-1 SHE70T 61.60 mm LINK HDCP TP IN HDMI OUT IR IN IR OUT 5-2 SHE70R... -
Page 13: Troubleshooting & Maintenance
Known issues with HDMI 1.2 source devices: Older compatibility (HDMI 1.2) may result in HDBaseT transmission issues. Please contact Technical Support of Stoltzen for a solution to these issues. Color lose or poor picture quality: Ensure that the HDMI cables used for both the source and transmitter and the receiver and display are properly connected and are of good quality. -
Page 14: After-Sales Service
Product version and name. Detailed failure situations. The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor, or contact Customer Support at www.stoltzen.com.
