- Page 1 User Manual Stoltzen SHE400K 4K HDMI Extender w/IR &RS232 All Rights Reserved Version: SHE400_2020V1.0...
- Page 2 Stoltzen SHE400 4K HDMI Extender w/IR &RS232 Statement Read this user manual carefully before using the product. Pictures shown in this manual is for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction only. The functions described in this version are updated till August 16, 2017.
- Page 3 Stoltzen SHE400 4K HDMI Extender w/IR &RS232 Features Supports HDMI1.4 & HDCP2.2. Maximum transmission distance is up to 40m for 4Kx2K, and 70m for 1080p. Supports bi-directional 5V IR and RS232 pass-through for long-distance control. Supports bi-directional PoC for simplified wiring.
- Page 4 Stoltzen SHE400 4K HDMI Extender w/IR &RS232 Panel Description Front Rear HDCP LINK Name Description ① Power LED Illuminates red when power is applied. ② RS232 Euroblock/Phoenix connector for connecting an RS232 data device. HDMI IN (TX) HDMI port for connecting the video source device (e.g. Blu-ray DVD) ③...
- Page 5 Stoltzen SHE400 4K HDMI Extender w/IR &RS232 Specification Model SHE400T SHE400R Spec Input HDMI IN HDBT IN Output HDBT OUT HDMI OUT Control IR IN, IR OUT, RS232 IR IN, IR OUT, RS232 General Maximum Video Resolution 4K×2K@60Hz 4:2:0, including 1080p@60Hz...
- Page 6 Stoltzen SHE400 4K HDMI Extender w/IR &RS232 Note: This picture is for reference only, the specific scheme is subject to real devices.
