- Page 1 User Manual Stoltzen SHE412 HDBaseT Extender All Rights Reserved Version: SHE412_2016V1.0...
- Page 2 Stoltzen SHE412 HDBaseT Extender Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till November 2016.
- Page 3 Stoltzen SHE412 HDBaseT Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
Stoltzen SHE412 HDBaseT Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to SHE412 ..................1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 Transmitter ......................2 2.2 Receiver ......................3 3. System Connection ..................... 5 3.1 Usage Precautions .................... -
Page 5: Introduction
SHE412 is a mini-size extender set consists of transmitter and receiver. HDBaseT technology is used to transmit high-resolution 1080p/ 4k signal from transmitter to the receiver via a CAT5e/CAT6a cable at a distance of up to 70/40m.Moreover, SHE412 support CEC, bi-directional RS232&IR control, and bi-directional PoH function. -
Page 6: Panel Description
Stoltzen SHE412 HDBaseT Extender 2. Panel Description 2.1 Transmitter LINK HDCP Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ②... -
Page 7: Receiver
Stoltzen SHE412 HDBaseT Extender Connect with power supply (Not necessary if receiver connects ⑨ DC 24V with power adaptor). Pictures shown in this manual are only for reference. 2.2 Receiver LINK HDCP Name Description HDBT Link status indicator: ... - Page 8 Stoltzen SHE412 HDBaseT Extender far-end IR IN port ⑦ HDMI OUT Connect with HDMI display Connect to the HDBT OUT socket on the transmitter via CAT5e/ ⑧ HDBT IN CAT6a cable. Connect with power supply (Not necessary if transmitter connects ⑨...
-
Page 9: System Connection
Stoltzen SHE412 HDBaseT Extender 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safety. -
Page 10: Application
Step6. Connect with DC24V power adaptor(s) One is enough if Transmitter or Receiver is connected with adapter as its PoH function). 3.4 Application SHE412 has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. -
Page 11: Specification
Stoltzen SHE412 HDBaseT Extender 4. Specification Model Transmitter Receiver Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw... -
Page 12: Supported Resolution
1280x720 60Hz 1024x576 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1280x1024 60/75/85/96Hz 1024x768 60/70/75/85Hz 800x600 56/60/72/75/85Hz 640x480 60/72/75Hz Note: SHE412 supports 4k HDMI signal, please adopt quality HDMI cables compliant with HDMI2.0 for reliable transmission. -
Page 13: Panel Drawing
Stoltzen SHE412 HDBaseT Extender 5. Panel Drawing LINK HDCP 115 mm 5-1 Transmitter 115 mm 5-2 Receiver... -
Page 14: Troubleshooting & Maintenance
Stoltzen SHE412 HDBaseT Extender 6. Troubleshooting & Maintenance No image on display: Ensure that the display device has been set to the correct input. Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation. -
Page 15: After-Sales Service
Stoltzen SHE412 HDBaseT Extender 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
