- Page 1 User Manual TP70SP 4K HDMI Extender w/IR &RS232 All Rights Reserved Version: TP70SP_2017V1.0...
-
Page 2: Safety Precaution
For more details, please contact your distributor. Introduction This TP70SP is an HDBaseT Extender set consist of transmitter (TX) and receiver (RX). It distributes HDMI signal via CAT5e/CAT6a cable at 70m/PoC, and enables IR and RS232 pass-through to control local source device from remote or far-end display. -
Page 3: Package List
4K HDMI Extender w/IR &RS232 Features Supports HDMI1.4 & HDCP2.2. Maximum transmission distance is up to 40m for 4Kx2K, and 70m for 1080p. Supports bi-directional 5V IR and RS232 pass-through for long-distance control. Supports bi-directional PoC for simplified wiring. ... -
Page 4: Specification
4K HDMI Extender w/IR &RS232 Specification Model Transmitter (TX) Receiver (RX) Spec Input HDMI IN HDBT IN Output HDBT OUT HDMI OUT Control IR IN, IR OUT, RS232 IR IN, IR OUT, RS232 General Maximum Video Resolution 4K×2K@60Hz 4:2:0, including 1080p@60Hz Transmission Mode HDBaseT Transmission Distance... - Page 5 4K HDMI Extender w/IR &RS232 Altimium www.altimium.com...
- Page 6 4K HDMI Extender w/IR &RS232 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com Altimium www.altimium.com...
