Introduction
This booklet contains instructions for the use and maintenance of the D and D HF series water pumps, both
single phase and three phase. The D and D HF electro pump has been designed to pump clean water not
containing abrasive particles it can be used in wells with a minimum diameter of 125 mm (5"), as well as in
containers or cisterns. The use of the pump for irrigation, gardening, and in the residential and household
field is subject to local legislation. Before installing and using the pump, read the following instructions
carefully.
Read this manual carefully before installing and using the product.
The manufacturer declines any responsibility in case of accidents or damages caused by improper
use of the water pump or due to negligence or lack of observance of the instructions described in this
booklet or use of the pump under conditions that differ from the ratings on the nameplate.

Description of the pump

The electro pump D and D HF is supplied in a solid carton box, with its instruction booklet, ready for
installation, complete with electric cable.
These data below:
Power I
Model W Max. Amp.
75M 850 4,6
100M 1100 5,9
150M 1600 7,8
200M 2300 10
100M HF 1100 6,2
150M HF 1690 8,1
200M HF 2140 10
Power I max.
Model W Amp.
75T 800 1,7
100T 1190 2,4
150T 1590 3,3
200T 2150 4,9
100T HF 1200 2,5
150T HF 1800 3,5
200T HF 2100 4,9
Stocking and handling
The pump should be stocked in vertical position, in a clean and dry place and inside its original
packing. When storing do not put weights or other boxes on top.
Never lift or transport the pump by its electric cable.
Preliminary inspection
Unpack the pump and check its integrity in all its components.
Check that the data on the nameplate are according to your needs. In particular the electrical data
(voltage, phase number, frequency, rated power and amps) have to correspond with those of the
power supply where you want to connect the pump.
1 phase pumps
Capacitor Fatt. Pot. Capacity L/min
mF Cos.Fi min
16 0,89 5
20 0,89 5
30 0,89 5
35 0,89 5
20 0,89 25
30 0,89 25
35 0,97 25
3 phase pumps
Fatt. Pot. Capacity L/min
Cos.Fi min max
0,78 10 80
0,78 10 80
0,80 10 80
0,80 10 80
0,80 25 200
0,79 25 200
0,82 25 200
Head m.c.a.
max min max
80 5 36
80 10 48
80 13 72
80 16 96
200 10 28
200 10 42
200 10 56
Head m.c.a.
min max
5 36
10 48
13 72
16 96
10 28
12 42
16 56
