Summary of Contents for IKEA FORNEBY 005.569.09

  • Page 1 FORNEBY...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Energy efficiency Before first use Menu structure Daily use Environmental concerns Clock functions IKEA guarantee Using the accessories Additional functions Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.
  • Page 5 ENGLISH WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be • activated.
  • Page 6 ENGLISH If the door or door seals are damaged, the appliance must • not be operated until it has been repaired by a competent person. Only a qualified person can carry out any service or repair • operation that involves the removal of a cover which gives protection against exposure to microwave energy.

  • Page 7: Safety Instructions

    ENGLISH Failure to maintain the appliance in a clean condition could • lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. Safety instructions Installation Depth of the appli‐ 567 mm Warning! Only a qualified person ance...
  • Page 8 ENGLISH replaced, this must be carried out by our • Do not let sparks or open flames to come Authorised Service Centre. in contact with the appliance when you • Do not let mains cables touch or come open the door. near the appliance door or the niche •...
  • Page 9 ENGLISH • Replace immediately the door glass Avoid microwave misuse (i.e. running the panels when they are damaged. Contact oven without any load or small load). the Authorised Service Centre. Internal lighting • Make sure the cavity and the door are wiped dry after each use.

  • Page 10: Installation

    ENGLISH Installation Warning! Refer to Safety The manufacturer is not chapters. responsible if you do not follow the safety precautions from the Safety chapters. Assembly This oven is only supplied with a main cable. Refer to the Assembly Instructions for the installation. Electrical installation Warning! Only a qualified person must do the electrical installation.

  • Page 11: Control Panel

    ENGLISH Control panel Control panel overview Fast Heat Microwave Confirm set‐ Timer Light Press Turn the knob power ting Select a heating function to turn on the appliance. Turn the knob for the heating functions to the off position to turn the appliance off. Display Display with key functions.
  • Page 12 ENGLISH Initial cleaning Before the first use, clean the empty appliance and set the time: 00:00 Set the time. Press Initial preheating Preheat the empty oven before the first use. Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h.

  • Page 13: Daily Use

    ENGLISH Step 1 Open the door and remove the child lock with the torx key supplied with the oven. Step 2 Fix the screw back after removing the child lock. Daily use Warning! Refer to Safety chapters. How to set: Heating functions Step 1 Turn the knob for the heating functions and select a heating function.
  • Page 14 ENGLISH MICROWAVE POWER MAXIMUM TIME 100 - 600 59:55 >600 If you open the door, the microwave function stops. To start it again, close the door. Press How to set: Microwave combi functions Step 1 Remove all accessories. Insert microwave bottom glass plate. Put the food on the microwave bottom glass plate.
  • Page 15 ENGLISH Heating function Application To bake pizza. To make intensive browning and a crispy bottom. Pizza Function To roast large pieces of meat on one level. To make gratins and to brown.The function with MW boost, power range: 100 - 600 W. Turbo Grilling + Baking on one shelf position.The function with MW boost, power range: 100 - 600 W.
  • Page 16 ENGLISH P1 - P... Enter the menu. Select Assisted Cook‐ Select the dish. Press Insert the dish to the oven. Confirm set‐ ing. Press ting. Assisted Cooking Frozen To make convenience food Legend Foods (e.g., french fries, potato wedges or spring rolls) Weight Automatic available.
  • Page 17 ENGLISH Dish Weight Shelf level / Accessory Beef roast / 1.5 - 2 kg 1; roasting dish on wire shelf braised (prime rib, top round, thick flank) Roast Beef, rare (slow cooking) 1; baking tray Roast Beef, medi‐ 1 - 1.5 kg; 4 - 5 Use your favourite spices or simply salt and um (slow cooking) cm thick pieces...
  • Page 18 ENGLISH Dish Weight Shelf level / Accessory Whole chicken 1 - 1.5kg; fresh 1; ceramic or glass casserole dish on wire shelf, MW suitable Use your favourite spices. Put the chicken breast-side down and turn it over after half of the cooking time.
  • Page 19 ENGLISH Dish Weight Shelf level / Accessory Chocolate muf‐ 2; muffin tray on wire shelf fins Loaf cake 1; loaf pan on wire shelf Baked potatoes 1 kg 1; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 2;...

  • Page 20: Clock Functions

    ENGLISH Clock functions Clock functions Clock Function Application When the timer ends, the signal sounds. Minute minder When the timer ends, the signal sounds and the heating function stops. Cooking time To postpone the start and / or end of cooking. Time Delay Maximum is 23 h 59 min.

  • Page 21: Using The Accessories

    ENGLISH How to set: Cooking time Step 1 Step 2 Step 3 Step 4 The display shows: 0:00 Choose a heating Press repeatedly: Set the cooking function and set Press: time. the temperature. Timer starts counting down immediately. How to set: Time Delay Step 1 Step 2 Step 3...

  • Page 22: Additional Functions

    ENGLISH Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. Baking tray: Push the tray between the guide bars of the shelf support. Microwave bottom glass plate: Use the microwave bottom glass plate only with microwave function.

  • Page 23: Hints And Tips

    ENGLISH Automatic switch-off For safety reasons the appliance turns off (°C) after some time, if a heating function works and you do not change any settings. 200 - 230 The Automatic switch-off does not work with the functions: Light, Time Delay. (°C) 30 - 115 12.5...
  • Page 24 ENGLISH Put the frozen, unwrapped food on a small To cook fruit and vegetables without upturned plate with a container below it, or defrosting them first, you can use a higher on a defrosting rack or plastic sieve so that microwave power.
  • Page 25 ENGLISH Cookware / Material Baking tray Wire shelf Microwave glass bottom plate Cookware for microwave use, e.g. crisp pan Recommended power settings for different kinds of food The data in the table is for guidance only. 700 - 1000 W Searing at the start of the cooking process Heating liquids 500 - 600 W...

  • Page 26: Care And Cleaning

    ENGLISH Microwave function Use wire shelf unless otherwise specified. Food Power Quantity Shelf posi‐ Time Comments tion Sponge cake 0.475 Bottom 8 - 9 Turn container around by 1/4, half‐ way through the cooking time. Meatloaf 25 - 27 Turn container around by 1/4, half‐...
  • Page 27 ENGLISH Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm wa‐ ter and a mild detergent. Use a cleaning solution to clean metal surfaces. Clean stains with a mild detergent. Cleaning Agents Clean the cavity after each use. Fat accumulation or other residue may cause fire.

  • Page 28: Troubleshooting

    ENGLISH Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until Disconnect the oven from the Put a cloth on the bottom of the oven is cold. mains. the cavity. Top lamp Step 1 Turn the glass cover to remove it.

  • Page 29: Technical Data

    ENGLISH Error codes ---°C The appliance door is closed. Turn the appli‐ ance off and on and set the microwave func‐ tion again. If the display shows an error code that is not in this table turn the house fuse off and on to restart the appliance.

  • Page 30: Energy Efficiency

    ENGLISH Energy efficiency Energy saving the residual heat. You can use that heat to keep the food warm. Make sure that the appliance door is closed When the cooking duration is longer than 30 when the appliance operates. Do not open min, reduce the appliance temperature to the appliance door too often during cooking.

  • Page 31: Environmental Concerns

    IKEA. The original sales receipt is required expenditure. On these conditions the EU as proof of purchase. If service work is guidelines (Nr.
  • Page 32 The dedicated After Sales Service for IKEA • Repairs caused by installation which is appliances: faulty or not according to specification. Please do not hesitate to contact IKEA After • The use of the appliance in a non- Sales Service to: domestic environment i.e. professional use.
  • Page 33 How to reach us if you need our service Please refer to the last page of this manual for the full list of IKEA appointed contacts and relative national phone numbers. In order to provide you with a...
  • Page 34 9 till 21. Weekdays +381 11 7 555 444 (ако позивате изван Србије) Цена позива у националном Понедељак – субота: 09 – 20 Србија 011 7 555 444 саобраћају Недеља: 09 – 18 (ако позивате из Србије) Eesti, Latvija, Україна www.ikea.com...
  • Page 36 21552 © Inter IKEA Systems B.V. 2023 AA-2350298-2...

This manual is also suitable for:

Forneby 105.577.86
