CHAPTER
TECHNICAL DATA
- Spindle motor
- Block diameter
- Compressed air connection min. 6 bar, max. 10 bar
- Average air consumption
- Stand-by operation
- Operation during milling cycle
- Illumination of the device
- Protection class
- Suction unit
All electrical circuits connected to the device must comply with overvoltage category II (or better)
of IEC/EN 60664-1.

Option 2: All in One Touch PC

- Weight - pivot arm with PC
- Maximum extendable length
- Maximum height
- Maximum height from bottom edge of milling unit 660 mm
- Protection class

COMPRESSED AIR REQUIREMENTS

- Maximal dew point temperatur Dpt + 3 °C in case of atmospheric pressure: Class 4 (according
to ISO 8573-1:2010).
-
-
-
separator.
- Recommendation: To protect the compressor, it should have a tank volume of at least 50 l and
48
ZIRKONZAHN – OPERATION AND MAINTENANCE MANUAL M1 MILLING UNIT COMPACT LINE – VERSION: 13/05/2021
200 W
Standard Ø 95 mm
100 l/min.
90 W
400 W
> 250 lux
IP20 according to IEC/EN 60529
extraction capacity 3000 l/min, vacuum 20 kPa,
7.9 kg
550 mm
500 mm
IP20 according to IEC/EN 60529
: Class 2 (according to ISO 8573-1:2010).
