TECHNICAL DATA

TECHNICAL DATA OF THE M1 MILLING UNIT

- Processing axes
- Overall height milling unit
- Depth milling unit
- Width milling unit
- Weight milling unit
- Weight front plate
- Glass cladding Hardened Sicurit glass UNI ISO 12150
- Width Cleaning Kit
- Electrical power
- Operating voltage
- Frequency
- Mains fuse
- Overvoltage category
- Degree of contamination
- Control voltage
- Stepper motor
-
- Collet chuck
- Direction of spindle rotation
- Spindle speed
ZIRKONZAHN – OPERATION AND MAINTENANCE MANUAL M1 MILLING UNIT COMPACT LINE – VERSION: 13/05/2021
5 or 4 M1 Abutment milling unit
690 mm
630 mm
477 mm
105 kg
5 kg
140 mm
600 W
100 - 240 V
50 - 60 Hz
6,3 A (rapid)
II
2
48 V
48 V
Ø 3 mm and Ø 6 mm
Clockwise
Standard version: max. 50.000 R.p.m.
