Installation Guide

1. Installation Steps

User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. The room thermostat should be installed at approx.
1.5 m above floor and where the effects of sunlight,
draught or other heat sources (eg. TV's) are avoided,
see fig. 1.
3. First of all, carefully remove the cover, see fig. 2.
4. Connect the wire before mounting the back plate
to the wall box using the enclosed screws, see fig 3.
Then mount the cover to the back plate, see fig 4.
2. Wiring
1. Dimensions, see fig. 5
2. Wiring diagram, see fig. 6 to fig.9
3. Follow the illustrations to complete the wiring:
1) Wiring for SPST on/off control
. RC-C4, see fig. 6
. RC-C2, see fig. 7
2) Wiring for SPDT on/off control
. RC-C4, see fig. 8
. RC-C2, see fig. 9
