Installation Guide
1. Installation Steps
User Guide can be downloaded from: heating.danfoss.com.
1. Installation must be done by an authorised
electrician.
2. The room thermostat should be installed at approx.
1.5 m above floor and where the effects of sunlight,
draught or other heat sources (eg. TV's) are avoided,
see fig. 1.
3. First of all, carefully remove the cover, see fig. 2.
4. Connect the wire before mounting the back plate to
the wall box using the enclosed screws. Then mount
the cover to the back plate, see fig 3.
2. Wiring
1. Dimensions, see fig. 4
2. Wiring diagram, see fig. 5 and fig. 6
3. Follow the illustrations to complete the wiring:
1) RC-T4, see fig. 5
2) RC-T2, see fig. 6
Danfoss Heating Solutions
GreenCon RC-T2/T4
VIE2D22P
GB
3
