Frequently Asked Questions
Fixscreen
(Minimal) Solar
®
1. How does this screen work?
The solar panel collects sunlight and converts it into energy to charge the battery. So, you can still use the
screen on days that are not as sunny thanks to the energy stored in the battery. Naturally, the solar panel must
always be in a place where it can get enough sunlight. The Fixscreen (Minimal) Solar's scope of application,
therefore, is also geographically defined based on this and on the prevailing weather conditions.
2. Can the Fixscreen (Minimal) Solar be used in any country?
The Fixscreen (Minimal) Solar is available worldwide, for countries between 52° Northern- and Southernlatitude
(between 52° N and 52° S). This scope of application is taken from the Somfy instructions. The Fixscreen
(Minimal) can be applied in the 'not possible' zones but always check off with the Solar by Somfy app.
Any use outside of the scope of application as defined by Renson is not in conformity. Because of this and a
disregard for the instructions in the manual, any liability and warranty on Renson's behalf become null and void
and the proper operation of your Fixscreen 100 Solar cannot be guaranteed.
52° N
52° S
03/24
RENSON
NOT POSSIBLE
NOT POSSIBLE
Headquarters  •  Maalbeekstraat 10  •  IZ 2 Vijverdam  •  B-8790 Waregem
®
Tel. +32 56 30 30 00  •  info@renson.eu  •  www.renson.eu
52° N
52° S
NOT POSSIBLE
52° N
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fixscreen Solar and is the answer not in the manual?

Questions and answers

Summary of Contents for Renson Fixscreen Solar

  • Page 1 (Minimal) can be applied in the 'not possible' zones but always check off with the Solar by Somfy app. Any use outside of the scope of application as defined by Renson is not in conformity. Because of this and a disregard for the instructions in the manual, any liability and warranty on Renson’s behalf become null and void...
  • Page 2 In below mentioned circumstances Renson recommends not to use the Fixscreen (Minimal) Solar. With Fixscreen Solar the solar panel mounted on a separate unit can be used, with cable length of 5 m.
  • Page 3 7. What is the adapter for the Oximo battery and how does it work? This is the battery’s charger. Can be ordered via RIO (art.no. 14487 (G6026311)), found under sun protection, accessories. • Fixscreen Solar with io motor Additional Battery...
  • Page 4 When the screen is delivered, the battery will be fully loaded. If the screen is installed shortly after delivery, the battery doesn’t need to be loaded again by means of the adapter. 03/24 RENSON Headquarters  •  Maalbeekstraat 10  •  IZ 2 Vijverdam  •  B-8790 Waregem ® Tel. +32 56 30 30 00  •  info@renson.eu  •  www.renson.eu...
  • Page 5 8. Can the solar panel be installed separately from the screen? Yes, this is possible for Fixscreen Solar with RTS motor. When ordering, there is a possibility to choose a solar panel mounted on a separate unit. The panel is connected to the box with a cable length standard 5 m. It is also necessary to choose the position of the cable throughput.
  • Page 6 12. Which type of motor is used for the Fixscreen (Minimal) Solar? The Fixscreen (Minimal) Solar is equipped with a radio-controlled Somfy RTS motor: Sunea 40 DC RTS. For Fixscreen Solar, the Somfy radio-controlled io motor is also available. Power supply...
