16 20-Port 100BASE-FX (MT-RJ) Fast Ethernet Layer 2 Switching Module Quick Start Guide

Administration Console Access

You can configure and manage the front panel ports on the FEN
Switching Interface Module using the Administration Console, which is a
command line interface that you access from a terminal that is connected
through the Enterprise Management Engine (EME).
1 Log in to the EME.
For information about logging in to the EME, see the CoreBuilder 9000
Enterprise Management Engine User Guide.
2 At the prompt, enter:
connect <slot>.1
Where is the chassis slot number of the module that you want to
<slot>
manage, and the number after the decimal point is a subslot number
(which is always 1).
The Administration Console displays the top-level menu prompt. For
example, if you installed a 20-port 100BASE-FX FEN Switching Module in
slot 4, then the prompt appears as follows:
CB9000@4.1 [20-E/FEN-FX-L2] ():
3 Enter commands to manage the module.
For example, to display a module baseline, enter:
module baseline display
For more information about Administration Console module commands,
see the Command Reference Guide.

Web Management Access

Web Management applications are an embedded part of the
CoreBuilder 9000 system software image. They include WebConsole,
DeviceView, and Performance monitoring tools. Also available is a Help
system. After you have set up the IP address for your CoreBuilder 9000
system, you can access the Web Management applications directly by
entering its IP address in your Web browser.
See the Web Management User Guide for the CoreBuilder 9000
Enterprise Switch for additional information about Web Management.
