4 20-Port 100BASE-FX (MT-RJ) Fast Ethernet Layer 2 Switching Module Quick Start Guide

Handling Precautions

Unpacking
Instructions
When you handle the 100BASE-FX (MT-RJ) Fast Ethernet Layer 2
Switching Module, follow these precautions:
Always handle the module by the front panel only.
Do not touch the components, pins, leads, or solder connections.
Do not twist or otherwise force the module into the chassis when you
insert it into the module guides.
Before you push the module into the chassis, make sure that the
module ejector handles are open.
When you slide the module into the 7-slot chassis, match the left and
right module guides. When you slide the module into the 8-slot
chassis, match the upper and lower module guides.
Use the following procedure when you unpack the module:
1 Verify that the module is the correct model by matching the 3C number
that is listed on the shipping box label to the 3C number that is listed on
your order documentation (3CB9LF20MM).
2 Remove the module, in its antistatic bag, from the shipping box.
3 Remove the module from its antistatic bag and inspect it for physical
damage.
CAUTION: Handle the module by the front panel only. Do not touch any
components, pins, leads, or solder connections.
If the module appears to be damaged, replace it in its antistatic bag and
shipping box, and contact your supplier.
4 Ensure that the box also contains:
CoreBuilder 9000 Release Notes for Fast Ethernet and Gigabit
Ethernet Layer 2 Switching Modules
20-Port 100BASE-FX (MT-RJ) Fast Ethernet Layer 2 Switching Module
Quick Start Guide for the CoreBuilder 9000 Enterprise Switch (this
guide)
If the listed contents are not included in your shipping box, contact your
supplier.
All shipping boxes are reusable. After you remove the contents, replace
the packing materials in the box and store it for future use.
