Ref. 563301
User manual
DVBS2 - COFDM CI
EN
w w w . t e l e v e s . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 563301 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Televes 563301

  • Page 1 Ref. 563301 User manual DVBS2 - COFDM CI w w w . t e l e v e s . c o m...
  • Page 3: Table Of Contents

    DVBS2 - COFDM CI Index Technical specifi cations ........................Reference description ......................... Mounting ............................. 3.1. Wall mounting ..........................3.2. 19” rack mounting ........................Element description ..........................4.1. Introduction ..........................4.2. Power supply unit ........................4.3. Amplifi er ..........................4.4. Universal programmer ......................How to use the product ........................
  • Page 5: Technical Specifi Cations

    1. Technical characteristics 1.1. DVBS2-COFDM CI ref. 563301 Input frequency 950 - 2150 MHz Through loss < 1,5 dB typ. DVB-S2 (QPSK, 8PSK) Symbol rate 10-30 Mbaud (QPSK- 8PSK) Modulation DVB-S (QPSK) LDPC (9/10, 8/9, 5/6, 4/5, 3/4, 2/3, 3/5,...
  • Page 6 DVBS2 - COFDM CI 1.2. Technical specs. Broaband Amplifi ers Frequency range 46 ... 862 MHz Connector “F” Gain 44 ± 2,5 dB Power supply 24 V Amplifi er 5575 Regulation margin 20 dB Consumption at 24 V 450 mA Output level (60 dB) 105 dBμV (42 CH CENELEC) Test socket...
  • Page 7: Reference Description

    2. Description of references Product Range Accessories 563301 T-0X DVBS2-COFDM CI 7234 Universal Programmer 5575 Broadband Amplifi er 44dB 120dBμV T-0X 5071 T03-T05-T-0X Mounting rail (50 cm) 451202 Amplifi er DTKom (47 - 862 MHz) 5239 T03-T05-T-0X Mounting rail.12 Modules+PSU (56 cm)
  • Page 8: Mounting

    DVBS2 - COFDM CI 3. Mounting 3.1. Wall mounting IF satellite 563301 5629 5575 input CLAC! 5071 5239 UPSU 120 Output COFDM 4061 7234 NOTE: The use of both source outputs is recommended, balancing the consumption. For example, 4+3 or 3+4 modules...
  • Page 9: 19" Rack Mounting

    3.2. 19” rack mounting 5301...
  • Page 10: Element Description

    DVBS2 - COFDM CI 4. Identifi cation of the system elements 4.1. Introduction 1. IF satellite input 2. IF satellite output 3. RF input 4. RF output CTRL 5. Module power supply input 6. Status LED 7. Control BUS connector 8.
  • Page 11: Power Supply Unit

    4.2. Power supply unit Connectors to power the modules (1) On LED 24V: OK 0V: Overload or short circuit 02340039001 003 Mains input 230V~ NOTES: - The power source can supply a maximum of seven DVBS2-COFDM CI T0X modules. - Whenever the demand of power exceeds 4A (max. current for each output), it is necessary to distribute it between the two powering outputs of the PSU.
  • Page 12: Amplifi Er

    DVBS2 - COFDM CI 4.3. Broadband amplifi er OPTION “A” - 5575 OPTION “B” - 451202 TEST (-30dB) +10 dB OK - MATV 20 dB 20 dB 10 dB 10 dB 20 dB MATV OK - Return USO EXCLUSIVO EN INTERIOR C.
  • Page 13: Universal Programmer

    4.4. Universal Programmer PCT 5.0 The programmer consists of 4 buttons: (short press) - Selection of parameter (posi- tioning of the cursor). P C T 4 . 0 Modifi cation of the parameter chosen by U N I V E R S A L the cursor (fl ashing) (short press) - Change menu...
  • Page 14: How To Use The Product

    DVBS2 - COFDM CI 5. - Instructions for use 5.1. Normal menu b. COFDM1 modulation menu Insert the programmer in the front connector of The next main menu allows various COFDM output the module programming (“PRGM”). First, the a. Input menu modulation parameters to be selected: programmer’s fi rmware version will appear: The fi rst main menu lets you select the input...
  • Page 15 c. COFDM2 modulation menu e. Service menu In frequency mode you can select any output frequency value between 45 - 862 MHz. The In the next main menu you can select the decimal part depends on the diff erence of This menu shows the list of transport stream parameter cell_id (cell identifi er) of the COFDM frequency chosen (see extended menu b).
  • Page 16: Extended Menu

    DVBS2 - COFDM CI g. Measurements menu 2 5.2. Extended menu that occupies the service indicated. The second number indicates the percentage of the output that is free. In the example, France 2 will occupy This menu indicates the occupancy rate of the When the key is held down for more than 3 18% of the output (it is OFF so it is removed) and...
  • Page 17 b. Identifi er menu c. Temperature measurement d. Versions menu menu Some DVB-T receivers can present problems In this menu the user is shown the fi rmware receiving transmodulator channels which share The following menu provides an indication of versions for the unit and the COFDM (FPGA) the same identifi er (transport_stream_id).
  • Page 18: Parameters Saving

    DVBS2 - COFDM CI f. LCN menu 5.3. Parameters saving Assign a LCN (Logical Channel Number) (between 1 and 1023) to the existing services at the output Once a parameter is modifi ed to the desired value (marked as ON or DCY). in any menu (normal or extended), to save the settings press for three seconds.
  • Page 19: Selecting The Dvb-T Output Mode In Dvbs2-Cofdm Ci Transmodulators

    6. - Selecting the DVB-T output GI=1/32 mode in DVBS2-COFDM Information service output (Mbits/sg) for GI=1/16 CI transmodulators DVB-T signals with a 64QAM modulation 31.67 in 8MHz channels. GI=1/8 30.74 30.16 The standard DVB-T defi nes various possible operation modes which enable the DVB-T signal 29.27 29.03 generated to adjust to the conditions of the...
  • Page 20 T mode selected is, the more powerful this mode can use the DVBS2-COFDM CI transmodulator, will be in terms of information service output Ref. 563301, by selecting a higher DVB-T output (Mbits/sg). mode than that used by terrestrial channels to On the other hand, the lower and further to the disseminate.
  • Page 21: Controlling The Device

    7. - Controlling the Device Menu structure This version of the DVBS2-COFDM CI T0X allows confi guration and monitoring via a PC, both locally and remotely. a. Local control The “Headend Management” programme (v2.13 ´ or higher) is required, as well as a special cable (provided with the programme) that connects a PC serial port to the DVBS2-COFDM CI T0X “PRGM”...
  • Page 22: Distribution Of 7 Channels Of Dvbs2-Cofdm Ci T0X

    DVBS2 - COFDM CI 8. Application example Distribution of 7 channels of DVBS2-COFDM CI T0X 75 ohm 4061 4512 5629 7 x 563301 COFDM output The diagram shows the assembly for the distribution of 7 channels of DVBS2-COFDM CI T0X...
  • Page 23: Norms For Rack Mounting

    9. Norms for rack mounting (max. 35 DVBS2-COFDM CI T0X - 7 subracks with 5 units in height - 8,7”) 9.1. Installation of the rack with These ventilators will be placed on a tray, that is screwed onto the top part of the Rack, fi g. 1 and 2. ventilation facilities This way, the ventilators will force the fresh air en- tering from the base of the cabinet, to circulate be-...
  • Page 24 DVBS2 - COFDM CI 9.2. Installation of the rack without It is very important that this process operates cor- rectly, therefore the following must be observed: ventilation facilities - Do not open the side doors, as this would cause the ventilators to extract the air from the outside To install the units in racks without installation rather than the air in the inside of the rack.
  • Page 25: Norms For Cabinet Mounting

    10. Norms for cabinet mounting IMPORTANT EXTRACTOR for forced ventilation must be onto The scheme of recommended the highest module. ventilation is the one in the fi gure in any case of cabinet placement (horizontal or vertical). Maximum environment temperature: 45ºC. Horizontal The maximum temperature placement...
  • Page 26 DVBS2 - COFDM CI IMPORTANT Horizontal placement of the cabinets is strongly recommended, hanging them HORIZONTAL with as less height as possible. If the horizontal placement is impossible, 0,2 m 0,2 m then vertical placement is allowed. Respect the recommended minimum distances in the attached schemes.
  • Page 27: Channels Table

    A. Channels table Table1 Table2 Table3 Table4 Table5 Table6 Table7 Table8 Table9 Table10 CCIR China/Taiwan Chile Italy France OIR channels Ireland South-Afric Poland (OIR) Australia 177,50 179,00 177,00 177,50 178,75 178,00 178,00 178,00 178,00 177,50 184,50 187,00 183,00 186,00 186,75 186,00 186,00 186,00...
  • Page 28 DVBS2 - COFDM CI 690,00 706,00 647,00 698,00 706,00 698,00 698,00 698,00 698,00 648,50 698,00 714,00 653,00 706,00 714,00 706,00 706,00 706,00 706,00 655,50 706,00 722,00 659,00 714,00 722,00 714,00 714,00 714,00 714,00 662,50 714,00 730,00 665,00 722,00 730,00 722,00 722,00 722,00 722,00...
  • Page 30 DVBS2 - COFDM CI Guarantee Televés S.A. offers a two year guarantee, beginning from the date of purchase for countries in the EU. For countries that are not part of the EU, the legal guarantee that is in force at the time of purchase is applied. Keep the purchase invoice to determine this date. During the guarantee period, Televés S.A.
