Parameter Name and Description
152
E C v2
Selects amount of droop that the speed
reference is reduced when at full load torque.
Zero disables the droop function.
Setting parameter 080 to 0 is recommended
when you are using the Droop function.
153
E C v2
Sets the maximum power limit transfer from
FV
the motor to the DC bus. When you are using an
external dynamic brake, set this parameter to its
minimum
(–800.0%) value. Overvoltage trips can occur if
set too negative and the connected brake is
unable to dissipate the energy.
154
E C v2
Sets the largest rate of change for the current
FV
reference signal. This number is scaled in
percent of maximum motor current every 250
microseconds.
189
E C
Sets the time that the drive is at or above
current limit before a fault occurs. Zero disables
this feature.
145
E C
Enables/disables dynamic brake operation.
Disabled = DB operates only when the drive is
running.
Enable = DB operates whenever the drive is
energized.
155
Standard
156
Standard
Active stop mode. [Stop Mode A] is active unless
[Stop Mode B] is selected by digital inputs that
are programmed for "Stop Mode B."
(1)
When you are using options 1 or 2, refer to
the Attention statements at [DC Brake Level].
E C v2
E C v2
See description above.
Rockwell Automation Publication 20A-UM001P-EN-P - February 2018
(1)
Values
[Droop RPM @ FLA] Default:
Min/Max:
Units:
[Regen Power Lim]
Default:
Min/Max:
Units:
[Current Rate Lim] Default:
Min/Max:
Units:
[Shear Pin Time] Default:
Min/Max:
Units:
[DB While Stopped]
Default:
Options:
[Stop Mode A] Default:
[Stop Mode B]
Default:
Options:
[Stop/Brk Mode A] Default:
[Stop/Brk Mode B]
Default:
Options:
Programming and Parameters Chapter 1
0.0 rpm
0.0/200.0 rpm
0.1 rpm
053
–50.0%
161
–800.0/0.0%
0.1% 162
163
400.0% 053
1.0/800.0%
0.1%
0.0 s
0.0/30.0 s
0.1 s
0 "Disabled"
0 "Disabled"
1 "Enabled"
1 "Ramp" 157
0 "Coast"
158
0 "Coast" 159
(1)
1 "Ramp"
161
(1)
2 "Ramp to Hold"
163
3 "DC Brake"
168
361...
1 "Ramp"
366
0 "Coast"
0 "Coast"
(1)
1 "Ramp"
(1)
2 "Ramp to Hold"
3 "DC Brake"
4 "Fast Brake"
E C v3
