www.proform.com
USERʼS MANUAL
Model No. PFTL14511.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-888-533-1333
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERFORMANCE 1450 and is the answer not in the manual?

Questions and answers

Summary of Contents for NordicTrack PERFORMANCE 1450

  • Page 1 www.proform.com USERʼS MANUAL Model No. PFTL14511.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE; please contact Customer Care.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.
  • Page 5: Before You Begin

    ® PERFORMANCE 1450 treadmill. The ual. To help us assist you, please note the product PERFORMANCE 1450 treadmill offers an impressive model number and serial number before contacting us. selection of features designed to make your workouts The model number and the location of the serial num- at home more enjoyable and effective.
  • Page 6: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 1. Make sure that the power cord is unplugged. Place a piece of cardboard below the rear of the Frame (56) to protect the floor or carpet. Attach the Left Wheel Cap (96) to the Base (94) with two #8 x 3/4" Screws (2). Attach the Right Wheel Cap (not shown) to the right side of the Base (94) in the same way.
  • Page 8 4. Hold the Left Upright (89) against the Base (94). Be careful not to pinch the Upright Wire (81). Insert two 3/8" x 1 1/4" Bolts (8) with two 3/8" Star Washers (13) and two 3/8" x 2 3/4" Bolts (7) into the Left Upright. Partially tighten the 3/8"...
  • Page 9 6. Cut the plastic tie in the Left Handrail (88) and the Right Handrail (not shown). If necessary, press the 5/16" Cage Nuts (31) back into place. Identify the Left Handrail (88) and hold it near the Left Upright (89). Insert the Upright Wire (81) through the bracket on the bottom of the Left Handrail.
  • Page 10 8. Set the console assembly face down on a soft surface to avoid scratching the console Console assembly. Assembly Remove all the Screws (A) attaching the Crossbar (93). Next, lift off the Crossbar. Discard the Screws. 9. IMPORTANT: To avoid damaging the Crossbar (93), do not use power tools and do not overtighten the #10 x 3/4"...
  • Page 11 11. Set the console assembly on the Right Handrail (87) and the Left Handrail (88). Be careful not Console to pinch any wires. Insert the excess Upright Assembly Wire (not shown) into the Left Handrail. Attach the console assembly with six #8 x 1/2" Screws (1) and four 1/4"...
  • Page 12 14. Hold the Left Upright Cover (79) against the console assembly. Align the holes in the Left Upright Cover with the holes in the Left Upright (89). Attach the Left Upright Cover with three #8 x 1/2" Screws (1). Attach the Right Upright Cover (80) to the Right Upright (90) in the same way.
  • Page 13 17. IMPORTANT: See page 15 and plug in the power cord. Next, see page 17 and turn on IMPORTANT: the power. Make sure to follow all instructions in this step. See page 27; follow steps 1 through 3. When the frame stops moving, remove the key from the console and unplug the power cord.
  • Page 14 19. Attach the Rear Feet (57) to the Frame (56) as shown with four #8 x 3/4" Screws (2). See step 16. Discard the piece of cardboard. Lower the Frame (56) (see HOW TO LOWER THE TREADMILL FOR USE on page 29). 20.
  • Page 15: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets and may not be compatible Your treadmill features a walking belt coated with high- performance lubricant. IMPORTANT: Never apply sil- with AFCI-equipped outlets.
  • Page 16 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even browse the Internet or listen to your fa- vorite workout music or audio books with the consoleʼs The treadmill console offers an impressive array of stereo sound system while you exercise. features designed to make your workouts more effec- To turn on the power, see page 17.
  • Page 17 HOW TO TURN ON THE POWER HOW TO SET UP THE CONSOLE IMPORTANT: If the treadmill has been exposed to Before using the treadmill for the first time, set up your cold temperatures, allow it to warm to room tem- console.
  • Page 18 HOW TO USE THE MANUAL MODE The browser will open to the iFit.com home page. Touch the Register Now button in the upper-right 1. Insert the key into the corner of the screen. console. The browser will open to the iFit.com registration page.
  • Page 19 4. Change the incline of the treadmill as desired. • The number of vertical feet you have climbed To change the incline of the treadmill, press the • Your heart rate (see step 6 on page 20). Incline increase and decrease buttons or one of the numbered 1 Step Incline buttons.
  • Page 20 6. Measure your heart rate if desired. speed of the fan will automatically increase and de- crease as the speed of the walking belt increases Before using the and decreases. handgrip pulse sensor, remove Press the Manual fan button repeatedly to select a the sheets of fan speed or to turn off the fan.
  • Page 21 HOW TO USE AN ONBOARD WORKOUT Each workout is divided into segments. One speed setting and one incline setting are programmed for 1. Insert the key into the console. each segment. Note: The same speed setting and/or incline setting may be programmed for con- See step 1 on page 18.
  • Page 22 2. Log in to iFit.com. To reset the console, touch the home button on the screen. To pause the workout, touch the Pause button. To continue the workout, touch the Resume If you have not already done so, log in to your button or the Start button.
  • Page 23 5. Start the workout. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to See step 4 on pages 21 and 22. Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- During some workouts, the voice of a personal ence in a residential installation.
  • Page 24 HOW TO USE THE INTERNET BROWSER button. Then, enter the address of the page and touch the Done button. Note: To use the browser, you must have access to a Find on page—A search box will appear on the bot- wireless network including an 802.11b/n router with SSID broadcast enabled (hidden networks are not sup- tom of the screen.
  • Page 25 HOW TO USE THE SETTINGS MODE An information box will ask if you want to connect to the wireless network. Touch the Connect button The console features a settings mode that allows you to connect to the network. Touch the Cancel button to connect the treadmill to your own wireless network to return to the list of networks.
  • Page 26 3. Log in to your iFit Live account. 6. Turn on or turn off the display demo mode. To log in to a different iFit Live account, touch the The console features a display demo mode, de- iFit Live Login button. Then, enter your user name signed to be used if the treadmill is displayed in a and password using the keyboard on the screen.
  • Page 27 HOW TO USE THE MAINTENANCE MODE 4. Calibrate the speed of the treadmill. The console features a maintenance mode that allows Calibrate the speed of the treadmill only if in- you to calibrate the incline and speed of the treadmill, structed to do so by an authorized service repre- update the console firmware, calibrate the screen, sentative.
  • Page 28 6. Calibrate the screen. 9. Access the Android™ desktop. Access the Android desktop only if instructed If the screen is not properly calibrated, it will be dif- to do so by an authorized service technician. ficult for you to touch the correct buttons on the screen.
  • Page 29: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.
  • Page 30: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 31 Locate the Reed Switch (52) and the Magnet (50) on the left side of the Pulley (49). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 1/8 in. (3 mm). If nec- essary, loosen the #8 x 3/4"...
  • Page 32 b. If the walking belt slips when walked on, first re- move the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller bolts clock- wise, 1/4 of a turn. When the walking belt is cor- rectly tightened, you should be able to lift each edge of the walking belt 2 to 3 in.
  • Page 33: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 34: Part List

    PART LIST Model No. PFTL14511.0 R0311A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Reed Switch Clip #8 x 3/4" Screw Reed Switch 3/8"...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Module Housing Right Tray Console Back Console Base Console Base Ground Wire Console Frame Hood Clip Ground Wire #10 x 3/4" Flat Head Screw Console Clamp 5/16" Flat Washer Left Tray – Userʼs Manual Note: Specifications are subject to change without notice.
  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL14511.0 R0311A...
  • Page 37 EXPLODED DRAWING B Model No. PFTL14511.0 R0311A...
  • Page 38 EXPLODED DRAWING C Model No. PFTL14511.0 R0311A...
  • Page 39 EXPLODED DRAWING D Model No. PFTL14511.0 R0311A...
  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
