USERʼS MANUAL
Model No. NTL11010.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-800-TO-BE-FIT
CALL TOLL-FREE:
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for NordicTrack NTL11010.1
Summary of Contents for NordicTrack NTL11010.1
- Page 1 USERʼS MANUAL Model No. NTL11010.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE; please contact Customer Care.
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at actual size. NordicTrack is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
14. To purchase a surge suppressor, see informed of all warnings and precautions. your local NordicTrack dealer or call the tele- phone number on the front cover of this man- 3. Use the treadmill only as described. - Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack ing this manual, please see the front cover of this man- ® COMMERCIAL 1500 treadmill. The COMMERCIAL ual. To help us assist you, please note the product 1500 treadmill offers an impressive selection of fea- model number and serial number before contacting us. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, some lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 1. Make sure that the power cord is unplugged. Place a piece of cardboard below the rear of the Frame (56) to protect the floor or carpet. Attach the Left Wheel Cap (96) to the Base (97) with two #8 x 3/4" Screws (1). Attach the Right Wheel Cap (not shown) to the right side of the Base (97) in the same way.
- Page 8 4. Hold the Left Upright (89) against the Base (97). Be careful not to pinch the wires. If nec- essary, position the Base Ground Wire (94) in the hole in the side of the Left Upright. Insert two 3/8" x 2 3/4" Bolts (7) and two 3/8" x 1 1/4" Bolts (8) with two 3/8"...
- Page 9 6. With the help of a second person, hold the con- sole assembly near the Left Upright (89). Connect the Upright Wire (84) to the console Console wire. See the inset drawing. The connectors Assembly should slide together easily and snap into place.
- Page 10 8. Identify the Left Handrail (87), which is marked with a “Left” sticker. Slide the Left Handrail be- tween the console assembly and the pulse Console assembly. Assembly Pulse Assembly Attach the Left Handrail (87) with two 5/16" x 2" Bolts (4), a 5/16"...
- Page 11 10. Make sure there is a piece of cardboard below the rear of the Frame (56). IMPORTANT: Make sure to follow all instructions IMPORTANT: See page 14 and plug in the in this step power cord. Next, see page 16 and turn on the power.
- Page 12 12. Remove the packaging material from the bottom of the Frame (56). See the inset drawing. Make sure that the 1/2" Rear Foot Nuts (111) are threaded all the way onto the Rear Feet (60). Turn the two Rear Feet all the way into the Frame.
-
Page 13: How To Use The Chest Pulse Sensor
HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR may remain activated longer than necessary, drain- ing the battery prematurely. The chest pulse sensor consists of two components: the chest strap and the sensor unit. Insert the tab on •... -
Page 14: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets and may not be compatible Your treadmill features a walking belt coated with high- performance lubricant. IMPORTANT: Never apply sil- with AFCI-equipped outlets. - Page 15 CONSOLE DIAGRAM Audio Jack FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the consoleʼs stereo sound system The treadmill console offers an impressive array of while you exercise. features designed to make your workouts more effec- To turn on the power, see page 16.
- Page 16 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
- Page 17 4. Change the incline of the treadmill as desired. The My Trail tab will show a track that represents 1/4 mile (400 meters). As you exercise, the flash- To change the incline of the treadmill, press the ing rectangle will show your progress. The My Trail Incline increase or decrease button or one of the tab will also show the number of laps you are com- numbered 1 Step Incline buttons.
- Page 18 6. Measure your heart rate if desired. Press the Manual fan button repeatedly to se- Note: If you use the handgrip pulse sensor and lect a fan speed or to the chest pulse sensor at the same time, the turn off the fan. Press console will not display your heart rate accu- the Auto fan button to rately.
- Page 19 HOW TO USE AN ONBOARD WORKOUT During the workout, the 1. Insert the key into the console. profiles on the speed and in- See HOW TO TURN ON THE POWER on page 16. cline tabs will Current Segment show your 2.
- Page 20 HOW TO USE AN IFIT LIVE WORKOUT If the speed or incline setting is too high or too low at any time during the workout, you can manually override the setting by pressing the Speed or Note: To use an iFit Live workout, you must have an Incline buttons;...
- Page 21 Press the iFit Live button to download the next the Speed increase button. The walking belt will workout in your queue. Press the My Trainer but- begin to move at the speed setting for the first seg- ton, the My Maps button, the World Tour button, or ment of the workout.
- Page 22 THE INFORMATION MODE Press the decrease button next to the Enter button. The display will show the contrast level of the display. The console features an information mode that keeps Press the Incline increase and decrease buttons to ad- track of treadmill information and allows you to person- just the contrast.
- Page 23 HOW TO USE THE STEREO SOUND SYSTEM Next, press the Play button Volume Decrease on your MP3 player, CD To play music or audio books through the consoleʼs player, or other personal stereo speakers, you must connect your MP3 player, audio player.
-
Page 24: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero percent before you fold the treadmill. Then, left. -
Page 25: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 26 Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 24). Remove the three #8 x 3/4" Screws (1). Carefully pivot the Motor Hood (71) off. Locate the Reed Switch (52) and the Magnet (50) on the left side of the Pulley (49). Turn the Pulley View until the Magnet is aligned with the Reed Switch.
- Page 27 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...
-
Page 28: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. - Page 29 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 30: Part List
PART LIST Model No. NTL11010.1 R0111A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw Reed Switch Clamp 5/16" x 3 3/4" Bolt Reed Switch 3/8"... - Page 31 Key No. Qty. Description Key No. Qty. Description Wheel Pulse Bar Top Console Base Pulse Ground Wire Console Pulse Bar Bottom Module Housing 1/2" Rear Foot Nut Fan Assembly 3/8" Flat Washer Handrail Spacer – Userʼs Manual Console Frame Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
-
Page 32: Exploded Drawing
EXPLODED DRAWING A Model No. NTL11010.1 R0111A... - Page 33 EXPLODED DRAWING B Model No. NTL11010.1 R0111A...
- Page 34 EXPLODED DRAWING C Model No. NTL11010.1 R0111A...
- Page 35 EXPLODED DRAWING D Model No. NTL11010.1 R0111A...
-
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
