Model No. NTL09707.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT THE
STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-866-362-4490
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.healthrider.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for NordicTrack COMMERCIAL NTL09707.1
Summary of Contents for NordicTrack COMMERCIAL NTL09707.1
- Page 1 USER'S MANUAL Visit our website at www.proform.com new products, prizes, fitness tips, and much more! Visit our website at www.healthrider.com new products, prizes, fitness tips, and much more! Visit our website at www.nordictrack.com new products, prizes, fitness tips, and much more!
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ -
Page 3: Important Precautions
To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 (See the drawing on page 5 for the location of the circuit breaker.) 21. Do not attempt to raise, lower, or move the treadmill until it is properly assembled.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack COMMERCIAL 1500 treadmill. The COMMERCIAL 1500 treadmill offers an impressive selection of fea- tures designed to make your workouts at home more enjoyable and effective. And when you’re not exercis-... -
Page 6: Assembly
This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 7 Upright Bolts and two Star Washers (not shown). Do not tighten the Bolts yet. With the help of a second person, lower the treadmill off the cardboard stand. 3. Identify the Right Upright Sleeve (96) and the Left Upright Sleeve (95). The Sleeves are la- beled.
- Page 8 4. With the help of a second person, hold the con- sole assembly near the Uprights (73, 74). Remove the tie from the Upright Wire Harness (75). Connect the Upright Wire Harness (75) to the Console Wire Harness (71). See the inset draw- ing.
- Page 9 9. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex key in a secure place; the hex key is used to adjust the walking belt (see page 23). To protect the floor or carpet from damage, place a mat under the treadmill.
- Page 10 If you purchase the optional chest pulse sensor (see page 19), follow the steps below to install the re- ceiver included with the chest pulse sensor. 1. Make sure that the power cord is unplugged. Remove the indicated 3/4" Screws (4) from the Pulse Receiver Cover (70) on the back of the Console Assembly (A).
-
Page 11: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call the telephone number on the front cover of this manual and order part number 146148, or see your local electronics store. - Page 12 When the manual mode of the con- sole is selected, the speed and incline of the treadmill can be changed with the touch of a button. As you ex- ercise, the console will display continuous exercise feedback.
- Page 13 The console features a display demo mode, designed to be used if the treadmill is displayed in a store. While the demo mode is turned on, the console will function normally when you plug in the power cord, switch the reset/off circuit breaker to the reset position, and insert the key into the console.
- Page 14 6. Select a display mode and monitor your progress with the display and the intensity level bar. As you walk or run on the treadmill, the display can show the following workout information: • The elapsed time.
- Page 15 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when you fold the treadmill to the storage posi- tion, or you may damage the treadmill.
- Page 16 4. Press the Start button to start the workout. A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings of the workout. Hold the handrails and begin walking.
-
Page 17: To Create A Custom Workout
To program a speed setting and an incline setting for the first one-minute segment of the workout, simply adjust the speed and incline of the treadmill as desired by pressing the Speed and Incline but- tons. When the first segment ends, a series of tones will sound and the current speed and incline settings will be saved in memory. - Page 18 4. Press the Start button to start the workout. A moment after you press the Start button, the treadmill will automatically adjust to the first speed and incline settings that you programmed previ- ously. Hold the handrails and begin walking.
- Page 19 HOW TO USE THE STEREO SOUND SYSTEM To play music or audio books through the console’s stereo speakers, you must connect your MP3 player, CD player, or other personal audio player to the con- sole. Locate the audio wire below the display on the console, and plug it into a jack on your MP3 player, CD player, or other personal audio player.
-
Page 20: How To Fold And Move The Treadmill
1. Hold the handrails and place one foot against one of the wheels. 2. Tilt the treadmill back until it rolls freely on the wheels. Carefully move the treadmill to the desired location. Never move the treadmill without tipping it back. To reduce the risk of injury, use extreme caution while moving the treadmill. -
Page 21: How To Lower The Treadmill For Use
HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. It may be neces- sary to push the frame forward as you pull the knob to the left. -
Page 22: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 23 TREADMILL FOR STORAGE on page 20). Next, re- place the two 3/4" Screws (not shown). Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 21). Run the treadmill for a few minutes to check for a correct speed reading.
- Page 24 PROBLEM: The console displays remain lit when you remove the key from the console SOLUTION: a. The console features a display demo mode, designed to be used if the treadmill is displayed in a store. If the displays remain lit when you remove the key, the demo mode is turned on. To turn off the demo mode, hold down the Stop button for a few seconds.
-
Page 25: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 26: Part List
PART LIST—Model No. NTL09707.1 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Cover Foot Rail Cushion Screw 3/4" Screw Handrail Cover Fastener Walking Platform Belt Guide Belt Guide Screw Front Isolator Platform Bolt, Front... - Page 27 Key No. Qty. Description Handrail Latch Assembly Latch Warning Decal 4" Wire Harness Clamp Screw Speaker Cover Rear Roller Washer Incline/Controller Wire Incline Stop Bracket Stop Bracket Spacer Key No. Qty. Description 1/2" Console Ground Screw Console Plate #8 x 3/4" Screw Lower Latch Bolt Transformer –...
- Page 28 EXPLODED DRAWING—Model No. NTL09707.1 R0907A To identify the parts shown on this EXPLODED DRAWING, see the PART LIST on pages 26 and 27.
- Page 29 EXPLODED DRAWING—Model No. NTL09707.1 R0907A...
-
Page 30: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
