Summary of Contents for Trelawny TCG125L
- Page 1 CONCRETE GRINDER Original instructions TCG125L • TCG125 540.2010 • 540.2020...
-
Page 3: Table Of Contents
Your new TRELAWNY power tool will more than satisfy your expectations. It has been manufactured under stringent TRELAWNY Quality Standards to meet superior performance criteria. You will find your new tool easy and safe to oper- ate, and, with proper care, it will give you many years of dependable service. - Page 4 DEsCRIpTION Of symbOLs The rating plate on your tool may show symbols. These represent important information about the product or instruc- tions on its use. Double insulated for additional protection Spindle thread: M14 Conforms to the relevant European Directives Refer to original instructions Production period, where the variable symbols are: yyyy-Www yyyy - year of manufacture, ww - calendar week number...
-
Page 5: Technical Specifications
Technical specifications model TCG 125L TCG 125 part Number 540.2010 540.2020 Voltage 110V~50Hz 230V~50Hz Power input 1010 W 1400 W No load speed 8000 min 10500 min Spindle thread Spindle thread length 20 mm 20 mm Cup wheel arbor Ø22.23 mm Ø22.23 mm Cup wheel maximum diameter 125 mm... -
Page 6: General Power Tool Safety Warnings
General power tool b) Use personal protective equipment. always wear eye protection. Protective equipment such safety warnings as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) prevent unintentional starting. Ensure the WaRNING! Read all safety warnings and switch is in the off-position before connecting all instructions. -
Page 7: Concrete Grinder Safety Warnings
5. sERvICE pressure is applied and the motor slows resulting in inefficient work and possible damage to the motor. a) Have your power tool serviced by a qualified ▪ Rags, cloths, cord, string and the like should never be repair person using only identical replacement left around the work area. - Page 8 7. ON/OFF switch not operate after supply recovering. To start operating 8. Spindle lock button the machine, first switch off and then switch on the 9. Brush shield lever of ON/OFF switch. 10. Fastening bracket ▪ Soft start and overload protection: This feature 11.
-
Page 9: Maintenance
The brush replaced simultaneously with genuine brushes at shield wears out along with the wheel. When replacing TRELAWNY service centre for warranty and post- the wheel if necessary change the brush as well. Loosen warranty service. - Page 10 Notes Carefully read the entire Original Instructions before using this product. The manufacturer reserves the right to make changes and improvements to the products and to alter specifications without prior notice. Specifications may differ from country to country. TCG 125L • TCG 125 TCG 125L •...
- Page 11 TCG 125L • TCG 125 pos. No. Ref.No. Description pos. No. Ref.No. Description 540.159403 540.147747 Body L50-55 Gear box HD 540.159392 540.361366 Screw К 4Х25 TORX 20 Button 540.157300 540.330335 O-ring 16X2B Guiding switch lever L 540.117795 540.146782 Lock button Pressure spring 0,4х4х25 540.330704 540.102100...
- Page 12 EN 60745-1, EN 55014-1, EN 55014, EN 61000-3-2, EN 61000-3-3 Date and place of issue, Rob Chapman, 1st January 2014 Commercial Director. Leamington Spa, England. Registered Office: Trelawny SPT Ltd, Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom DOCUMENT No. Q:57/4...
