- Page 1 CONCRETE GRINDER Original instructions TCG 180L • TCG 180 540.2030 • 540.2040...
-
Page 3: Table Of Contents
Carefully read through these original instructions before using your new TRELAWNY power tool Take special care to heed the Warnings. Your TRELAWNY power tool has many features that will make your job faster and easier. Safety, performance, and dependability have been given top priority in the development of this tool, making it easy to maintain and operate. - Page 4 DEsCRIpTION Of symbOls The rating plate on your tool may show symbols. These represent important information about the product or instruc- tions on its use. Double insulated for additional protection Spindle thread: M14 Conforms to the relevant European Directives Refer to original instructions Production period, where the variable symbols are: yyyy-Www yyyy - year of manufacture, ww - calendar week number...
-
Page 5: Technical Specifications
Technical specifications model TCG 180l TCG 180 part Number 540.2030 540.2040 Voltage 110V~50Hz 230V~50Hz Power input 2000 W 2600 W No load speed 6500 min 6500 min Spindle thread Spindle thread length 20 mm 20 mm Cup wheel arbor Ø22.23 mm Ø22.23 mm... -
Page 6: General Power Tool Safety Warnings
General power tool b) Use personal protective equipment. always wear eye protection. Protective equipment such safety warnings as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) prevent unintentional starting. Ensure the WaRNING! Read all safety warnings and switch is in the off-position before connecting all instructions. -
Page 7: Concrete Grinder Safety Warnings
5. sERvICE pressure is applied and the motor slows resulting in inefficient work and possible damage to the motor. a) Have your power tool serviced by a qualified ▪ Rags, cloths, cord, string and the like should never be repair person using only identical replacement left around the work area. -
Page 8: Operation
6. Auxiliary handle press button (8) and the release switch (7). ▪ Switching off: Release switch (7); in case the switch is 7. ON/OFF switch locked, first press and then release that switch. 8. ON/OFF switch locking button In case of mains drop-out (or temporary drop-out 9. -
Page 9: Maintenance
When the carbon brushes are worn out, the machine switches itself off. In this case both brushes must be replaced simultaneously with genuine brushes at TRELAWNY service centre for warranty and post- warranty service. GENERal INspECTION Regularly inspect all fasteners and ensure they are properly tightened. - Page 10 TCG 180L • TCG 180...
- Page 11 TCG 180L • TCG 180 pos. No. Ref.No. Description pos. No. Ref.No. Description 540.178878 540.361360 Gear box Screw К 4Х9.5 TORX 20 540.330125 540.361433 Bearing HK 1212 Screw 3.9x80 540.330944 540.154350 Bearing 6300 2RSL P63 LDS18SpA 540.151648 Protective washer 540.153341 Gasket 540.331149 Bearing 608-2RS-P63...
-
Page 12: Declaration Of Conformity
EN 60745-1, EN 55014-1, EN 55014, EN 61000-3-2, EN 61000-3-3 Date and place of issue, Rob Chapman, 1st January 2014 Commercial Director. Leamington Spa, England. Registered Office: Trelawny SPT Ltd, Trelawny House, 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom DOCUMENT No. Q:57/4...
