Cooper Lighting Shaper 645 Series Specification Sheet

D E S C R I P T I O N
645 classic vanity features a rectangular shape providing
direct/indirect illumination.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Solid aluminum construction
with a white acrylic diffuser.
F i n i s h
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Laquered Satin
Aluminum (SAL), Matte White
(MW) or Custom Colors (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 645-18-CFL/1/27-277V-SAL
Series Size Lamp
645 Classic = 18" CFL/1/27
Vanity 1
24" INC/2/60
2
INC/3/60
2
T5/2/14
Notes:
1
Available in 18".
2
Available in 24".
3
Available with CFL only.
4
Consult the factory for available options.
5
Supplied by others.
L a m p / S o cke t
18": One (1) 27W (2G11) high
lumen CFL lamp or two (2) 60W
A-19 lamps.
24": Two (2) 14W T5 linear
fluorescent lamps or three (3)
60W A-19 lamps. Fluorescent
socket injection molded plastic.
INC socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 3" or
4" J-box or plaster ring.
O p t i o n s
Fluorescent Dimming Ballast -
Contact the factory for ballast
options (DM), Remote
Emergency Battery - Supplied by
others (REM), MRI Applications
Voltage Finish
120V
Standard
3
NA Natural Aluminum =
277V
3
347V
Premium
CC Custom Color =
MW Matte White =
SAL Lacquered =
Satin Aluminum
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
(INC only) - Contact the Factory.
Damp Location (DL): All Painted
finishes only. Energy Star Rating
- Consult factory.
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location =
4
DM CFL Dimming Ballast =
5
REM Remote Emergency Battery =
shaperlighting.com
Type
Date
645 SERIES
I n t e r i o r W a l l L u m i n a i r e
S t a r t e r C o l l e c t i o n
C l a s s i c Va n i t y
STARTER
COLLECTION
Shaper's exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
