DESCRIPTION
641-WP Quarter Sphere Wall Sconce features indirect illumination.
SPECIFICATION FEATURES
Material
Painted aluminum or solid bronze.
Internal lamp assembly is cast
aluminum with clear acrylic lense
for CFL and tempered clear lense
for incandescent and metal halide.
Finish
Natural bronze or premium TGIC
polyester powder coat paint, 2.5
mil nominal thickness for superior
protection against fade and wear.
Standard: Natural Bronze (NBZ)
[Sustainable Design]. Note: Bronze
will weather to a dark bronze
patina. Premium: Black (BK), Grey
(GY), White (WH), Dark Platinum
(DP), Graphite Metallic (GRM),
Silver Metallic (SM), Gold Metallic
(GM), Bronze Metallic (BM),
Verdigris (VG), Lacquered Satin
Chrome (SCL), Lacquered Satin
Nickel (SNL) or Custom Color (CC).
Optics
Refer to www.shaperlighting.com
for complete photometrics.
ORDERING INFORMATION
Sample Number: 641-WP-MH/1/70-277V-BK
Series
Lamp
641-WP Quarter
=
CFL/1 (26/32/42W-Triple)
Sphere
INC/1/150
MH/1/50
MH/1/70
Notes:
1 CFL and MH only.
2 Available with CFL only.
3 Premium TGIC polyester powder coat paint,
2.5 mil nominal thickness for superior
protection against fade and wear.
4 Bronze will weather to a dark bronze patina.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada), thermally
protected with end-of-life circuitry
to accommodate the specified
lamp wattage. Metal halide ballasts
are electronic HPF, multi-volt
120/277V for the specified lamp
wattage. 347V ballast for metal
halide - Contact factory.
Lamp/Socket
One (1) 26W, 32W (GX24q-3) or
42W (GX24q-4) 4-pin triple tube
CFL lamp, one (1) 50W or 70W
metal halide ED-17 lamp, or one (1)
150W A-21 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Metal halide socket is
ceramic pulse-rated, 4KV. Lamps
furnished by others.
Voltage
Finish
120V
Standard
=
1
NBZ Natural Bronze
277V
2
347V
Premium
=
BK Black
=
BM Bronze Metallic
=
CC Custom Color
=
DP Dark Platinum
=
GM Gold Metallic
=
GRM Graphite Metallic
=
GY Grey
=
SCL Lacquered Satin Chrome
=
SM Silver Metallic
=
SNL Lacquered Satin Nickel
=
VG Verdigris
=
WH White
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Installation
Supplied with a universal circular
strap for a standard 4" J-box or
stucco ring. Optional rear (through
wall) feed conduit mounting.
Options
Rear (through wall) Feed Conduit
Mounting (C). Energy Star Rating -
consult factory.
Labels
U.L. and C.U.L. approved for wet
location.
Modifications
Shaper's skilled craftspeople with
their depth of experience offer the
designer the flexibility to modify
standard exterior wall luminaires
for project specific solutions.
Contact the factory regarding scale
options, unique finishes,
mounting, additional
materials/colors, or decorative
detailing.
3, 4
Options
=
C Rear (through wall)
Feed Conduit Mounting
shaperlighting.com
Type
Date
641-WP SERIES
Exterior Wall Luminaire
Quarter Sphere
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Refer to the Icon Legend
Link on shaperlighting.com.
ADS042798
08/05/2008 11:36:18 AM
