Remove tools, wood scraps, etc. from the table
before the table saw is turned on. Distraction or a
potential jam can be dangerous.
■
Always use saw blades with correct size and shape
(diamond versus round) of arbour holes. Saw blades
that do not match the mounting hardware of the saw will
run off-centre, causing loss of control.
■
Never use damaged or incorrect saw blade mounting
means such as flanges, saw blade washers, bolts
or nuts. These mounting means were specially
designed for your saw, for safe operation and optimum
performance.
■
Never stand on the table saw, do not use it as a
stepping stool. Serious injury could occur if the product
is tipped or if the cutting tool is accidentally contacted.
■
Make sure that the saw blade is installed to rotate
in the proper direction. Do not use grinding wheels,
wire brushes, or abrasive wheels on a table saw.
Improper saw blade installation or use of accessories
not recommended may cause serious injury.
RIP FENCE USE
WARNING! To reduce the risk of injury, always make
sure the rip fence is parallel to the blade before beginning
any operation.
■
Loosen the rip fence by lifting the locking lever.
■
Place the rear lip on the rear of the saw table and pull
slightly toward the front of the unit.
■
Lower the front end of the rip fence onto the guide
surfaces on top of the front rail.
■
Check for smooth gliding action.
■
Position the rip fence the desired distance from the
blade.
■
With the rip fence flat on the saw table, push the fence
towards the front rail to align the fence to the blade.
WARNING! Lock the fence at the intended cut size first
then move the work piece up to the fence. Do not place the
work piece first then move your fence up to it to lock the
fence. This may result in a misaligned fence which could
pinch the workpiece against the saw blade and create
kickback.
■
Push the locking lever down to align and secure the
fence. When securely locked, the locking lever should
point downward.
NOTE: Ensure the locking lever secures the rip fence in
place.
NOTE: If the rip fence is not parallel to the blade,
adjustments are needed.
ADDITIONAL SAFETY WARNINGS FOR TABLE SAWS
■
Ambient temperature range for tool during operation is
between 0 ˚C and 40˚ C.
■
Ambient temperature range for tool storage is between
0 ˚C and 40˚ C.
■
The recommended ambient temperature range for the
charging system during charging is between 10 ˚C and
38˚ C.
SPECIFIC SAFETY INSTRUCTIONS FOR WOOD
CUTTING BLADE
■
Please read the manual and instructions carefully before
using the saw blade and the power tool.
■
The power tool must be in good condition, the spindle
without deformation and vibration.
■
Ensure the operator is adequately trained in safety
precautions, adjustment and operation of the power tool.
■
Always wear goggles and ear protection when using the
power tool. It is recommended to wear gloves, sturdy
non slipping shoes and apron.
■
Before using any accessory, consult the instruction
manual. The improper use of an accessory can cause
damage and increase the potential for injury.
■
Keep the blade clean. This includes saw dust and
particularly sticky substances like wood resin. A clean
blade cuts more accurately and safely.
■
Use only blades specified in this manual, complying with
EN 847-1.
■
Observe the maximum speed marked on the saw blade.
Ensure the speed marked on the saw blade is at least
equal to the speed marked on the saw.
■
Always use blades with correct size and shape of arbor
holes. Blades that do not match the mounting hardware
of the saw will run eccentrically, causing loss of control.
■
Do not use saw blades with a body thickness greater
or a width of the groove cut (kerf) smaller than the
thickness of the riving knife.
■
Do not use blades of larger or smaller diameter than
recommended. Do not use any loose washers or
spacers to make the blade fit onto the spindle.
■
Check the tips of the saw blade for damage or abnormal
appearance before each use. Tips that are damaged or
loose can become flying objects in use and increase the
risk of personal injury.
■
Do not use cracked or distorted saw blades. Do not use
saw blades that are damaged or deformed.
■
Scrap the saw blade if damaged, deformed, distorted or
cracked, repairing is not permitted.
■
Do not use HSS blades.
■
Ensure the saw blade is mounted correctly, tighten the
arbor nut securely before use.
■
Fastening screw and nuts shall be tightened using the
appropriate spanner, etc.
■
Using an extension on the spanner or tightening using
hammer blows is not permitted.
■
Make sure the blade and flanges are clean and the
recessed sides of the collar are against the blade.
■
Make sure the blade rotates in the correct direction and
does not contact any part of the machine or guarding
system.
■
Before work, make a dummy cut without the motor
turned on so the position of the blade, operation of the
guards with respect to other product parts and work
piece may be checked.
■
Never leave the power tool unattended.
■
Do not apply lubricants on the blade when it is running.
■
Never attempt to stop the power tool in motion rapidly
by jamming a tool or other means against the blade,
5
Original Instructions
