Summary of Contents for Hunter Channelside 59634
- Page 1 Channelside Installation Manual Model: 59634 Noble Bronze 59635 Brushed Nickel Fan weight ±2 lbs: 19.2 lbs (8.7 kg) ©2018 Hunter Fan Co. PG3727 r122018...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 1886 Here is what comes in your box: Hunter Pro Tip: We recommend that you pull everything out of the box and lay it out. We have Do not discard the hardware bags or mix parts from grouped the drawn components below with the hardware you’ll need for those different bags.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Ceiling Bracket Downrod Hanging Fan Wiring... -
Page 7: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Secure each blade to a blade iron as shown using the blade nuts, found in the hardware bag, and the blade assembly screws, found in the... -
Page 9: Installing The Switch Housing
1886 Installing the Switch Housing 2 of 6 Switch Housing Assembly Screws Screw two housing assembly screws from the hardware bag halfway into the motor housing. It does not matter which two screw holes you choose. Feed the wire plug through the center hole of the upper switch housing, then wrap keyhole slots around the screws and twist counterclockwise. - Page 10 1886 Installing the Light Kit 1 of 6 Switch Housing Assembly Screws WARNING Turn the light kit counterclockwise until the light kit screws are firmly situated in the narrow end of the keyhole slots. FAN FALL HAZARD Install the third screw, found in the hardware bag, into Make sure screws are tight to secure the place and then tighten all three screws.
- Page 11 1886 Installing the Pull Chains Feed the pull chains from the fan switch and the light switch down through the holes in the upper switch housing as shown. Attach the pull chain pendants to the light and fan pull chains. The fan pull chain controls the speed: from high to off.
-
Page 12: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... - Page 13 1886 Downrod If you need a different downrod length follow these steps: Follow steps 1-5 to remove standard downrod pipe Follow steps 6-10 to reassemble with new downrod WARNING FAN FALL HAZARD To prevent SERIOUS INJURY or DEATH: • ALWAYS follow the downrod assembly instructions exactly.
