Hunter Kennicott 51114 Installation Manual

Premier bronze, matte silver, dusty green, mattle black, fresh white

Advertisement

Quick Links

Model: 51114 Premier Bronze
51115 Matte Silver
59612 Dusty Green
59613 Matte Black
59614 Fresh White
Fan weight ±2 lbs: 17.4 lbs (7.9 kg)
Kennicott
Installation Manual
©2020 Hunter Fan Co.
PG3779 r052120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kennicott 51114 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunter Kennicott 51114

  • Page 1 Kennicott Installation Manual Model: 51114 Premier Bronze 51115 Matte Silver 59612 Dusty Green 59613 Matte Black 59614 Fresh White Fan weight ±2 lbs: 17.4 lbs (7.9 kg) ©2020 Hunter Fan Co. PG3779 r052120...
  • Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This product conforms to UL Standard 507.
  • Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
  • Page 4: Choosing The Right Installation Location

    A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit.
  • Page 5: Installing The Ceiling Bracket

    You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box.
  • Page 6: Hanging The Fan

    1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary.
  • Page 7: Wiring The Fan

    If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the...
  • Page 8: Installing The Blades

    1886 Installing the Blades: Insert the blade into the blade slot around the center screw. Put the blade washers found in hardware bag onto the blade screws found in the hardware bag. Then install the blade screws to secure each blade to the fan.
  • Page 9 1886 Installing Wall Control Turning off the power WARNING Ensure the power is OFF at the outlet box and wall switch location before proceeding To avoid possible electrical shock, before with installation. installing your fan, disconnect the power by turning off the circuit breakers to the outlet box associated with the wall switch location.
  • Page 10: Troubleshooting

    • Turn the power off, support the fan carefully, and check that the hanger ball is properly seated. • Use the provided balancing kit and instructions to balance the fan. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching.
  • Page 11: Limited Lifetime Warranty

    Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
