SVAT ELECTRONICS Now You Can See Wireless Color Mini Pinhole Security Camera System COMPLETE SYSTEM Instruction Manual Model # WSE103 www.svat.com... - Page 2 SVAT ELECTRONICS Now You Can See WSE103 www.svat.com...
-
Page 3: Product Warranty & Registra Tion
USA 14305 Warranty Terms SVAT products are guaranteed for a period of one year from the date of purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at SVAT's option. -
Page 4: Table Of Contents
1 Color Camera Portable Battery Clip 4 PIN DIN to RCA Wire (male) T IS COMP T IS COMP The WSE103 is compatible with TVs, VCRs, DVRs, computers and other SVAT systems including: WSE103C WSE201C WSE103 Mounting Bracket 2 Power Adapters... -
Page 5: Features
For best transmission, avoid installations where there are thick walls or major obstructions between the camera and receiver • Ensure there are no obstructions in the camera's view, to maximize viewing area. WSE103 SVAT ELECTRONICS Now You Can See ALLA TION ALLA... -
Page 6: Installing The Camera
Place the receiver either on top or near your TV. Rotate the antenna to a vertical position. Set your TV to VIDEO INPUT mode to view your camera. For recording camera footage using your VCR, see advanced features. WSE103 SVAT ELECTRONICS Now You Can See (TRANSMITTER) (TRANSMITTER) -
Page 7: Avoiding Interference
Multi-Camera Operation The WSE103 is designed to work with up to 3 cameras. Additional cameras are sold separately (indoor - WSE103C / outdoor - WSE201C). *IMPORTANT When using more than one camera, make sure you assign each camera a specific channel (1-3). -
Page 8: Operating Modes
SVAT ELECTRONICS Now You Can See OPERATING MODES The system can be set to operate in one of 2 modes: AUTO or MANUAL. The desired operating mode can be selected using the buttons on the front panel of the receiver. -
Page 9: Troubleshooting
Make sure each camera is within range, and that no obstructions are blocking the signal. Try repositioning the camera, receiver, or both to improve the reception quality. Reposition other nearby equipment transmitting on the 2.4 GHz frequency. SVAT ELECTRONICS Now You Can See... -
Page 10: Specifications
SVAT ELECTRONICS Now You Can See SPECIFICA TIONS SPECIFICA TIONS INDOOR RECEIVER Number of Cameras Supported ...3 Wireless Frequency...2.4GHz Channel Frequencies ...2.414, 2.432, 2.468 Motion Activated Alert ...No Audio Activated Alert ...No Output terminal ...4 PIN DIN to RCA Auto-Scanning ...Yes Housing Material ...ABS plastic... - Page 11 SVAT ELECTRONICS Now You Can See Focal Length ...6.0 mm Focus Type ...Fixed Focus Microphone ...No Motion Detection ...No Audio Activation...No Sun Shield ...No Housing Material ...ABS plastic Housing Color ...Midnight Black Electronic shutter speed ...1/60-1/15,000 sec Signal/Noise Ratio...48dB Power LED Indicator ...No Camera Bracket ...Yes...
-
Page 12: Notes
SVAT ELECTRONICS Now You Can See NOTES NOTES WSE103... - Page 13 SVAT ELECTRONICS Now You Can See T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS Crime Stoppers programs are operated as non-profit charities and are managed by a volunteer board of directors who raise funds and pay rewards to individuals who anonymously call with information that helps solve crime.
- Page 14 SVAT ELECTRONICS Now You Can See T SUPPORTS CRIME ST OPPERS T SUPPORTS CRIME ST OPPERS To receive more information about Crime Stoppers or to make a charitable donation please fill in the fields below, cut on the dotted line and mail in.
- Page 15 SVAT ELECTRONICS Now You Can See WSE103 www.svat.com...
- Page 16 SVAT ELECTRONICS Now You Can See w w w . s v a t . c o m w w w . s v a t . c o m D i s c l a i m e r S VAT d o e s n o t e n d o r s e a n y o f S VAT p r o d u c ts f o r a n y i l l e g a l a c t i v i t i e s .
