- Page 1 Instruction Manual MP006 Mobile Hydraulic Scissor Lift Table 660 lbs. (300 kg)
- Page 2 WARNING! Read this operation manual carefully and understand fully the operating instructions. Improper use of this unit could result in injury • DO NOT put foot or hand in scissor mechanism. • Keep neighbouring persons away from the unit when in use. •...
- Page 3 Wheel Weight Height Strokes to Elevate 300 kg. 500 x 815 mm 280-900 mm 127 mm 77 kg. MP006 ≤ 32 660 lbs. 19.7" x 32.1" 11" x 35.4" 5" 169 lbs. Service Instructions Change hydraulic oil every 12 months...
- Page 4 LIFT TABLE PARTS LIST Part Model Description Qty. SPIII.1-00 Handle Bar GB5781-2000 Bolt GB95-1985 Washer GB93-1987 Washer GB41-86 MP021 Wheel SPC.5-00 Frame SP.0-08 Shaft SP.0-04 Swivel Wheel GB894.1-86 Retaining ring SP.0-11 Shaft SP.0-12 Bush GB894.1-86 Retaining ring SPS.0-03 Shaft YQ-7 Retaining ring GB894.1-86 Retaining ring...
- Page 5 PUMP PARTS LIST Part Model Description Qty. GB3452.1-86 O-ring SP.8-11 Pump cylinder UHS18 YX-seal ring DH18 Dust ring SP.8-10 Pump plunger SP.8-09 Spring SP.8-08 Spring seat GB894.1-86 Retaining ring SP.0-13B Joint plate SP.0-14 JF.1-17 Screw JB892-77 Copper washer 6W804.1-12 Damp valve YQ-03 Spring YQ-02...
- Page 6 HANDLE PARTS LIST Part Model Qty. Description GB879-86 Spring pin SPAIII.1.01 Handle Bar MP015 Knob MP017 Screw Pull rod...
