- Page 1 P R E M I U M P L U S H E A D S E T S...
-
Page 2: Table Of Contents
CONTENTS Getting to know your... Controls Indicator Lights Charging Base FocusLight Audio signals Setting up with your... Computer Telephone with a headset jack Telephone without a headset jack Cell phone or tablet Electronic hookswitch Remote handset lifter... - Page 3 CONTENTS How to... Make a call on your desk phone Answer a call on your desk phone Use UniBase Technology ® Adjust volume & mute Activate auto-on Turn on call control Pair a secondary headset Charge a secondary headset Pair a new primary headset Troubleshooting &...
-
Page 4: Getting To Know Your
GETTING TO KNOW YOUR HEADSET CONTROLS Speaker Volume Up & Mute Speaker Volume Down & Mute FocusLight Headset ON/OFF Battery Battery Door WHAT’S IN THE BOX Battery Door Headset 8.5v AC Adapter Charging Base RJ-9 Phone Cord Lithium-Ion Battery Type C-to-A USB Cord... -
Page 5: Indicator Lights
GETTING TO KNOW YOUR INDICATOR LIGHTS DEVICE LIGHTS 100% Battery Life 75% Battery Life 50% Battery Life 25% Battery Life Computer Mode Bluetooth Mode* Telephone Mode *LH670 & LH675 models only. Bluetooth Status Bluetooth Status* lights up when your headset is on and is connect- ed to a Bluetooth Device. -
Page 6: Charging Base
GETTING TO KNOW YOUR CHARGING BASE Battery Charge Level Computer Mode Bluetooth Mode* Telephone Mode Button Bluetooth Status* Charging Cradle USB Connector Port Power Port AUX Port Telephone Connector Port Handset Connector Port RHL/DHSG Switch Compatibility Switch Microphone Volume Up/Down *LH670 &... -
Page 7: Focuslight
GETTING TO KNOW YOUR FOCUSLIGHT On a call Ringing* Muted Headset and base pairing Headset battery below 15% (only headset will flash) Headset and base not paired Solid Flashing *Your base will only flash if you have a handset lifter or other remote answering device... -
Page 8: Audio Signals
GETTING TO KNOW YOUR AUDIO SIGNALS SOUND WHAT IT MEANS Ringtone Incoming desk phone call 1 click Volume up/down 1 chime Volume max/min reached 2 beeps (5 min repeat) Mute is on 1 beep Mute is off 2 beeps (60 sec repeat) Low Battery (≤30 min remaining) Triple tone UniBase activated... -
Page 9: Setting Up With Your
Use the included USB cable to connect your computer to the USB port If your computer doesn't recognize the device after a minute, go to your sound settings and select "Leitner Headset" as both your default microphone and default speakers. - Page 10 SETTING UP YOUR TELEPHONE WITH A HEADSET JACK If your desk phone has a headset button and a RJ9 headset jack on the back, you can connect through there, here's how! Plug the power adapter into the power port on the charging base. Plug the included phone cord into the green telephone connector port the back of the charging base.
-
Page 11: Telephone With A Headset Jack
SETTING UP YOUR TELEPHONE WITHOUT A HEADSET JACK Plug the power adapter into the power port on the charging base. Disconnect the curly cord from your phone base and plug it into the blue handset port Plug the included phone cord into the green telephone connector port Plug the other end of the phone cord into the handset jack of your phone... -
Page 12: Cell Phone Or Tablet
SETTING UP WITH YOUR CELL PHONE OR TABLET If you have an LH670 or LH675 model, you can connect to any Bluetooth device. With the headset turned off, press and hold the Bluetooth button until it begins to flash, then let go. Go into your device's Bluetooth settings and look for "DECT Headset"... -
Page 13: Remote Handset Lifter
SETTING UP WITH YOUR HANDSET LIFTER A handset lifter is an optional accessory that will physically lift your handset when you turn on the headset, answering the call. Follow the instructions for headset setup through the handset jack. Remove the outer covering of the double-sided tape on bottom of the lifter and attach it under your handset on the phone. -
Page 14: How To
HOW TO MAKE A CALL Make sure telephone mode is enabled. Press the ON/OFF button . If you have a lifter or EHS cable, the line will automatically connect (proceed to step 4). Press the headset button on your phone if one is available. -
Page 15: Answer A Call On Your Desk Phone
HOW TO ANSWER A CALL Make sure telephone mode is enabled. Remove your headset from the base and press the ON/OFF button . If you have a handset lifter or EHS cable connected to the charging base, the line will be connected automatically (proceed to step 4). -
Page 16: Use Unibase ® Technology
HOW TO USE UNIBASE ® UniBase Technology allows you to conference calls between any two devices. Have a call on your cell phone and one on your landline? Conference them together with UniBase! While on a call, press and hold the other mode button for the call you want to conference in until both mode lights are illuminated. -
Page 17: Adjust Volume & Mute
HOW TO ADJUST VOLUME & MUTE TO ADJUST LISTENING VOLUME: While the headset is on, click the volume control buttons on the headset to raise or lower the volume. The headset will beep each time the volume is adjusted. TO MUTE THE MICROPHONE: Press and hold either of the volume control buttons ) for 1 second. -
Page 18: Activate Auto-On
HOW TO ACTIVATE AUTO-ON Turn this feature on if you’d like your headset to turn on automatically when you pick up your headset off the charging base. To turn this feature on: With your headset turned off, hold both volume buttons on your headset together for three seconds. -
Page 19: Pair A Secondary Headset
HOW TO CONNECT A SECONDARY HEADSET Turn on the primary headset. With the secondary headset turned off, place the secondary headset on the charging base. The secondary headset's FocusLight will flash purple to show that the headset is pairing. Once the pairing has completed, the headset's FocusLight will begin flashing blue. -
Page 20: Charge A Secondary Headset
HOW TO CHARGE A SECONDARY HEADSET Having a secondary headset is useful for training purposes or when you have multiple people working at the same desk throughout the day. On the back of your headset, pull back the rubber cover to expose the USB port. -
Page 21: Pair A New Primary Headset
HOW TO REGISTER A NEW PRIMARY HEADSET In the event that you need to replace your headset, you’ll need to register it to your charging base Set the headset onto the charging base. The FocusLight on the base will flash blue then go solid purple when the headset goes into pairing mode. -
Page 22: Troubleshooting & Frequently Asked Questions
4 hours. Check the battery orientation inside of your headset. The arrow on the battery should be pointing into your headset and the Leitner Logo facing the buttons of the headset. My headset is charged and turned on but I can’t hear anything. - Page 23 Make sure the USB cord is connected between your charging base and comput- er. If your computer doesn’t automatically recognize your headset, go to your computer’s sound settings and make sure "Leitner Headset" is selected as your output and input device. Your sound settings can be found on most Windows computers by searching ‘sound settings’...
-
Page 24: Health And Safety Instructions
It might seem a bit silly, but we’re required to tell you these safety instructions about your Leitner headset. Please keep these instructions for your reference. When using this product, these basic safety precautions and warnings should be followed to reduce the risk of fire, electrical shock, injury to persons, and damage to property. - Page 25 • Avoid contact with liquids. Do not place this product near water, for example, near a bathtub, or sink, in a wet basement, or near a swimming pool. • Discontinue use of product if the product overheats, has a damaged cord or plug, if the product has been dropped or damaged, or if the product has come into contact with liquids.
- Page 26 Headset Battery Warnings • The headset is equipped with a replaceable battery. To reduce the risk of fire or injury to persons read and follow these instructions. • Do not dispose of the battery in a fire. The battery may explode. Check your local laws for disposal instructions.
- Page 27 For live product suppor t 1- 800 - 432-3738 Mon - Fri 9am -7pm Eastern Time w w w.leitnerheadsets.com...
