Summary of Contents for Leitner SmartSet 370
- Page 1 ® SmartSet 370 Manual ™...
- Page 2 What’s in the box: • Wireless Headset • Charging Base • Lithium-Ion Battery • AC Adaptor • Phone Cord • Mini USB Cord • Windscreen...
-
Page 3: Table Of Contents
2 .5 Setting up your Leitner Electronic Hookswitch Cable (optional) . . . . . . . . . . . . . . . 5 2 .6... -
Page 4: Product Features & Functions
Product features & functions Charging Base 1 . Battery indicator 2 . Computer Mode button 3 . Bluetooth Mode button 4 . Office Telephone Mode button 5 . Indicator lights (see section 3 . 1 3 on page 10) 6 . USB connector jack 7 . - Page 5 Headset 1 . Listening volume up/down 2 . Microphone mute button 3 . Headset ON/OFF (and Online Indicator) 4 . Battery 5 . Battery door...
-
Page 6: Setup
2. Setup Activating and charging the battery • Carefully remove the tab from the headset to activate the battery . Plug one end of the power supply into the power jack on the back of the charging base and the other end into a working power outlet •... -
Page 7: Setting Up Your Leitner Handset Lifter (Optional)
Ensure that the accessory selection switch on the bottom of your base is set to RHL • Want to see the setup video? Go to headsets .com/LifterSetup Setting up your Leitner Electronic Hookswitch (EHS) Cable (optional) • Connect the EHS cable to your telephone as shown in its user guide •... -
Page 8: Connecting To Your Computer
Connecting to your computer • Connect the included USB cable to the USB connector jack on the back of the charging base and the other end to an available USB jack on your computer • Your computer may automatically recognize the device and install the correct drivers . -
Page 9: Using Your Headset
Using your headset Making an outgoing call in Telephone mode • Ensure that the Telephone mode button on top of the charging base is selected • Turn the headset on . The base’s 3rd indicator light will light up • If a handset lifter or electronic hookswitch is connected, the line will be engaged automatically . -
Page 10: Making An Outgoing Call In Computer Mode
Making an outgoing call in Computer mode • Ensure that the computer button on the top of the headset base is selected • Press the headset’s ON/OFF button • After finishing your call, press the ON/OFF button to disconnect • You may also need to click your softphone’s disconnect button to end the call Making a call in Bluetooth mode •... -
Page 11: Adjusting The Ring Volume
Adjusting the ring volume • When the headset is ringing to indicate an incoming call, you can adjust the ring volume using the volume control buttons located on the headset . Your headset must be turned off in order to adjust the ring volume Muting the headset microphone •... -
Page 12: Battery Level Lights
3.12 Battery level lights • The four LEDs on the top of the headset base (left side) indicate the battery level of your headset battery Light (left to right) Battery Level One LED flashing < 20% One LED on 20%-40% Two LEDs on 40%-60% Three LEDs on... -
Page 13: Training Mode And Making A Conference Call
3.14 Training mode and making a conference call Your Leitner headset allows a second headset to be temporarily connected to the base for training or conference calls • Turn on the primary headset • Place the second headset on the charging base* •... -
Page 14: Overview Of Audio Signals
3.15 Overview of audio signals Sound Indication 2 rapid beeps (60 sec repeat) Low battery 2 beeps Nearly out of range 2 pitch tone Out of range 4 rapid beeps Back in range 1 beep Receiver volume up/down 2 pitch tone (8 sec repeat) Mute is on 1 beep Mute off/on... -
Page 15: Permanently Register An Additional Headset
3.17 Permanently register an additional headset • With the original headset out of the base, press and hold the Volume Up button underneath the base for about five seconds to enter registration mode . The Telephone Mode light on the base will begin to flash to indicate you’re in registration mode •... -
Page 16: Troubleshooting
Health and Safety Instructions Please read the following safety and operational instructions before using your Leitner SmartSet 370 headset . Please keep these instructions for your reference . When using this product, these basic safety precautions and warnings should be followed to reduce... - Page 17 Warnings • Never allow children to play with the product - small parts may be a choking hazard • Plug the AC adaptor into the outlet nearest the equipment that is easily accessible • To reduce the risk of electrical shock, explosion or fire, use only the supplied charger or Class 2 AC adaptor to charge the headset .
- Page 18 Charging warnings To avoid the risk of electrical shock, explosion, fire or leakage of corrosive or toxic chemicals, please observe the following charging and battery warnings: • Use only the charger provided with your headset to charge the product . Do not use the charger for any other purpose .
- Page 19 To protect your hearing, some hearing experts suggest you: • Set the volume control in a low position before putting your headset on your ear and use as low volume as possible • Avoid turning up the volume to block out noisy surroundings . Whenever possible, use your headset in a quiet environment with low background noise •...
- Page 20 © Leitner Headsets For live product support: Call 1-800-432-3738 Mon-Fri 6:00am-4:30pm Pacific Time...
