■ CONNECTION DIAGRAM
Note: In order to improve EMC performance, bond the FE terminal to ground.
Caution: FE terminal is NOT a protective conductor terminal.
*1
*1
CONFIGURATION
USB Connector
CONNECTOR
*1. The network cable can be connected to either one.

MOUNTING REQUIREMENTS

2−M4
1
+24V
2
NC
3
GND
4
X0
1
+24V
2
NC
3
GND
4
XF
1
+24V
2
NC
3
NC
4
Y0
1
+24V
2
NC
3
NC
4
YF
1
PWR+
2
PWR–
3
FE
4
SNSR.EXC+
5
SNSR.EXC–
1
PWR+
2
PWR–
3
FE
4
SNSR.EXC+
5
SNSR.EXC–
unit: mm [inch]
175 (6.89)
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
■ 2-Wire Sensor
Detecting INPUT X0
Circuit
•
•
•
•
•
Detecting
INPUT XF
Circuit
OUTPUT Y0
•
•
•
•
•
OUTPUT YF
POWER SUPPLY (IN)
SENCOR EXCITATION
(IN)
POWER SUPPLY (OUT)
SENCOR EXCITATION
(OUT)
R7I4DML3-DAC32C
1
+24V
2
NC
Detecting Circuit
3
GND
4
Xn
EM-8008-B P. 6 / 12
