Cooper Lighting Shaper 417SERIES Specification Sheet

SHAPER ™
416 SERIES
416 Luminous Shade Pendant.
417 SERIES
417 Direct/Indirect Luminous
Pendant.
418 SERIES
418 Direct/Indirect Luminous Bowl
Pendant.
960
COOPER LIGHTING
6-1/4" ø
2-1/8"
24"
12-1/2"
9" ø
CFL
Sample Number: 416-CFL/1/26-347V-SAL-__
Series Lamp Voltage
416 =Luminous CFL/1/26 120V
Shade CFL/1/32 277V 1
CFL/1/42 347V 1
INC/1/100
Notes:
1 Available with CFL only.
2 Consult the factory for available options.
3 Supplied by others.
4 For Stem mounting only. Specify up to 45°.
6-1/4" ø
2-1/8"
24"
9-1/2"
3-1/2"
4" ø
14" ø
417 CFL
Sample Number: 417-HAL/1/50-120V-SAL-__
Series Lamp Voltage
417=Direct/Indirect CFL/1/26 120V
Luminous Bowl CFL/1/32 277V 1
CFL/1/42 347V 1
INC/1/100
HAL/1/50
Notes:
1 Available with CFL only.
2 Consult the factory for available options.
3 Supplied by others.
4 For Stem mounting only. Specify up to 45°.
6-1/4" ø
2-1/8"
24"
3-1/2"
3" ø
14-1/2" ø
14" ø CFL
Sample Number: 418-18-CFL/1/26-347V-SAL-__
Series Size Lamp Voltage
418= 14" CFL/1/26 120V
Direct/Indirect 18" CFL/1/32 277V
Luminous Bowl INC/1/100
347V
Notes:
1. Available with CFL only. Notes:
2. Consult the factory for available options.
3. Supplied by others.
4. For Stem mounting only. Specify up to 45°.
4-1/2" ø
1/2"
24"
12-1/2"
9" ø
9" ø
INC
Suspension
Finish Options Height
NA (standard), 1S
24"
CC, MW, PCP, CSJ Or Specify
SAL, SCP PSS2SD
PSS3SD
PSS4SD
DL
DM 2
REM 3
4
SCA
4-1/2" ø
1/2"
24"
9-1/2"
3-1/2"
4" ø
14" ø
417 INC
Suspension
Finish Options Height
NA (standard), 1S 24"
CC, MW, PCP, CSJ Or Specify
SAL, SCP SSS2SD
SSS3SD
SSS4SD
DL
DM 2
REM 3
SCA 4
6-1/4" ø
2-1/8"
24"
5"
3" ø
18" ø
18" ø CFL
Suspension
Finish Options Height
NA 1S 24"
1 (standard), CSJ Or Specify
1 CC, MW, SSS2SD
PCP, SAL, SSS3SD
SCP SSS4SD
DL
DM 2
REM 3
SCA 4
CD
MATERIAL
LAMP/SOCKET
Solid aluminum or solid
One (1) 26W, 32W
copper materials. Matte
(GX24q-3) or 42W
white acrylic diffuser. (GX24q-4) 4-pin triple CFL
Supplied with an SJ cord
lamps or one (1) 100W
assembly. Single stem is
A-19 lamps. CFL socket
standard suspension.
injection molded plastic.
Minimum 18" (OA). INC socket fired ceramic
rated for 660W-250V.
BALLAST
Lamps furnished by
Integral electronic HPF,
others.
multi-volt 120/277V (347V
FINISH AND OPTIONS
Canada), thermally
See page 1020 for finish
protected with end-of-life
details and options.
circuitry to accommodate
the specified lamp
wattage.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided
with option stem.
MATERIAL
LAMP/SOCKET
Solid aluminum One (1) 26W, 32W
materials. Matte (GX24q-3) or 42W
white acrylic, one piece.
(GX24q-4) 4-pin triple
Single stem is standard
CFL lamp or one (1) 100W
suspension. Minimum
A-19 or 50PAR20H lamp.
18" (OA). CFL socket injection
molded plastic. INC
BALLAST
socket fired ceramic
Integral electronic HPF,
rated for 660W-250V.
multi-volt 120/277V (347V
Lamps furnished by
Canada), thermally
others.
protected with end-of-life
circuitry to accommodate
FINISH AND OPTIONS
the specified lamp
See page 1020 for finish
wattage.
details and options.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
MATERIAL LAMP/SOCKET
Solid aluminum
One (1) 26W or 32W
materials. Matte white
(GX24q-3) 4-pin triple CFL
acrylic bowl and optional lamp or one (1)100W A-19
Cone Diffuser (CD). lamp. CFL socket
Single stem is standard injection molded plastic.
suspension. Minimum
INC socket fired ceramic
18" (OA). rated for 660W-250V.
Lamps furnished by
BALLAST
others.
Integral electronic HPF,
FINISH AND OPTIONS
multi-volt 120/277V (347V
See page 1020 for finish
Canada), thermally
details and options.
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
