Page 2
June 2023 Safety messages NOTICE This guide provides basic guidelines for the Emerson Wireless 1410S Gateway. It does not provide instructions for diagnostics, maintenance, service, or troubleshooting. Refer to the Emerson Wireless Gateway 1410S Reference Manual for more information and instructions.
Physical security is an important part of any security program and fundamental to protecting your system. Unauthorized personnel may cause intentional or unintentional damage or misconfiguration of the Emerson Wireless 1410S Gateway and connected field devices. Restrict physical access by unauthorized personnel to protect end users’ assets.
This will result in a simpler and faster network installation. 1.2 Gateway redundancy If the wireless gateway was ordered with redundancy (Gateway Redundancy code RD), refer to Appendix D in the Emerson Wireless 1420 Gateway Reference Manual for additional installation instructions.
Configuration of the gateway is done through a secure web interface. Recent versions of the following browsers are supported: • Chrome browser ™ • Mozilla Firefox ® • Microsoft Edge 2.3 Hard disk space • AMS Wireless Configurator: 1.5 GB • Gateway Setup CD: 250 MB Emerson.com...
Powering the Gateway For the Emerson Wireless 1410S Gateway, bench top power will be needed to power the Gateway by wiring a 10.5–30 VDC power source. An Emerson Wireless 1410S Gateway can also be powered via Power over Ethernet (PoE) and is compliant with the IEEE 802.3af standard.
Page 8
Quick Start Guide June 2023 Figure 3-1: Emerson Wireless 1410S1 Gateway Wiring A. DIN-rail release tab B. 781S terminal 1 power and data connections C. 781S terminal 2 power and data connections D. Ethernet port 1. When this port is activated, the factory IP address is 192.168.1.10.
Page 9
Proceed to Section 3.5 for updating user information. Section 3.2-3.4 can be ignored for a DeltaV Ready Gateway. Emerson Wireless 1410S2 Gateway hardware revision 1.0.0 configured with Intrinsically Safe Outputs option “A” can only be powered by 24 VDC power source.
Page 10
Quick Start Guide June 2023 3.2 Windows 10 Procedure 1. Select the network icon in the lower right corner of the Windows 10 workspace. 2. Select the Network & Internet Settings link. Figure 3-3: WiFi Connections Menu Emerson.com...
Page 11
June 2023 Quick Start Guide 3. Select Change adapter options. Figure 3-4: Network & Internet Settings 4. Right click the network interface connection that the gateway is plugged into, and select Properties. Quick Start Guide...
Page 12
5. Select Internet Protocol Version 4 (TCP/IPv4) → Properties. Figure 3-5: Ethernet properties Note If the PC/laptop is from another network, record the current IP address and other settings so the PC/laptop can be returned to the original network after the gateway has been configured. Emerson.com...
Page 13
June 2023 Quick Start Guide 6. Select the Use the following IP address button. Figure 3-6: IP Address Properties 7. In the IP Address field, enter 192.168.1.11. 8. In the Subnet mask field, enter 255.255.255.0. 9. Select OK for both the Internet Protocol (TCP/IP) Properties window and the Local Area Connection Properties window.
Page 14
This procedure may be necessary when using a Chrome browser with Windows operating systems. Procedure 1. Open web browser. 2. Navigate to Settings → Advanced. 3. In the System section, click Open proxy settings. Example Figure 3-7: Proxy settings menu. Only use if a proxy is needed. Emerson.com...
Page 15
June 2023 Quick Start Guide 3.4 Configure the Gateway To complete initial configuration for the gateway, follow the steps below. This will have to be done be done for both networks. Procedure 1. Access the default web page for the gateway at https:// 192.168.1.10.
Page 16
For DeltaV Ready Gateways, access gateway web interface from DeltaV Explorer. 2. Change admin, operator, maintenance, and executive passwords to a secure password that adheres to user’s password requirements. Emerson.com...
Page 17
June 2023 Quick Start Guide Figure 3-10: Navigating to User Accounts page NOTICE Changing passwords is HIGHLY SUGGESTED before installing the gateway for full use. WARNING There is no way to recover lost passwords. The only way to access a gateway that no longer has known credentials is to factory reset the gateway.
Find a location where the gateway has convenient access to the host system network (process control network). 4.1.1 1401S1 DIN-rail mounting The Emerson Wireless 1410S1 Gateway can be snapped onto a DIN TS35/7.5 or TS35/15 rail system. To clip the gateway onto the DIN rail, Figure 4-1.
Page 20
2. Use a 1/2-in. wrench to fasten the nuts to the u-bolt. 3. Repeat for the second u-bolt and the lower mounting holes. Figure 4-2: Emerson 1410S2 Mounting 4.1.3 1410S2 Surface mount The following hardware and tools are needed to surface mount the...
Page 21
June 2023 Quick Start Guide • Wrench (not supplied) Mount the gateway using the following procedure: Procedure Install gateway into surface as shown in Figure 4-3. Screws shown as example. Figure 4-3: Emerson 1410S2 Surface Mounting Quick Start Guide...
Page 22
Quick Start Guide June 2023 4.2 Wiring the Emerson 1410S to Power and 781S Smart Antenna(s) Prerequisites • Compatible cable • Screwdriver • Wire strippers • For the Emerson Wireless 1410S1 Gateway, the connectors require a 12-30 AWG cable that meets the ambient temperature requirements of the end installation.
Page 23
Figure 4-4 Figure 4-5). Note 781S shield must be connected at gateway. Figure 4-4: Emerson 1410S1 Wiring diagram with 781S smart antenna A. Emerson Wireless 1410S1 Gateway B. Terminal connections C. Shielded, twisted pair cable D. Emerson Wireless 781S Smart Antenna E.
Page 24
Note Wire colors are typical of Belden 3084a cable or equivalent. Emerson Wireless 1410S2 Gateway hardware revision 1.0.0 configured with Intrinsically Safe Outputs option “A” can only be powered by 24 VDC power source. Check label to verify hardware revision.
Page 25
June 2023 Quick Start Guide 4.3 1410S1 LED Indicators and 1410S2 LED Indicators Both the 1410S1 and 1410S2 have LED indicators to show status of different operations of the Gateway and Antenna. The LED status is outlined below. Figure 4-6: 1410S1 LED Indicators Figure 4-7: 1410S2 Indicators with LED 1 through 5 from Left to Right Table 4-1: 1410S LED Indicator Descriptions...
Page 26
4.4 Emerson 1410S grounding 4.4.1 Emerson 1410S1 grounding The Emerson Wireless 1410S1 Gateway is grounded through the DIN- rail mounting plate on the back of the gateway. The DIN-rail should always be grounded in accordance with national and local electrical codes.
Page 27
Insulate the shield to avoid grounding issues. 4.7.1 Security best practices For security best practices, please see Emerson Wireless Security Whitepaper. User is solely responsible for the security of their system and products installed on such systems. These recommendations are in addition to user’s product and cybersecurity policies.
Configurator as needed. See Reference Manual for further information. The gateway firmware needs to be compatible with host connections being made. Verify that gateway firmware and host firmware (e.g. Security Setup Utility (SSU) and Plantweb Insight) are compatible before commissioning. Emerson.com...
June 2023 Quick Start Guide 6 Verify operations Operation is verified through the web interface by opening a web browser from any PC on the host system network and entering the gateway IP address or DHCP host name in the address bar. Log in using credentials set in Section 3-5.
A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide. The most recent revision of the EU Declaration of Conformity can be found at Emerson.com. 7.1.2 Ordinary location certification As standard, the transmitter has been examined and tested to...
Page 31
June 2023 Quick Start Guide Conditions of Acceptability (X) 1. Installed as per control drawing 01410-1300 for Hazardous and Non-Hazardous areas. 2. Installation “ic”, Um has been defined as 30Vdc. The 1410S1 can only be supplied with a SELV/PELV power supply. 3.
Page 33
June 2023 Quick Start Guide T4 (-40 °C ≤ T ≤ 70 °C) Temperature code Special Conditions for Safe Use(X) 1. Installation “ic”, Um has been defined as 30 Vdc. The 1410S1 can only be supplied with SELV/PELV power supply. 2. The 1410S1 do not pass the 500Vac requirement from the IS outputs to Earth (IEC/EN 60079-11, clause 6.3.13).
Page 34
A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide. The most recent revision of the EU Declaration of Conformity can be found at Emerson.com. 7.2.2 Ordinary location certification As standard, the transmitter has been examined and tested to...
Page 35
June 2023 Quick Start Guide (-40° C ≤ T ≤ 65 °C ), Temperature Code Conditions of Acceptability (X): 1. Installed as per control drawing 01410-1300 for Hazardous and Non-Hazardous areas. 2. Installation “ic”, Um has been defined as 30Vdc. The 1410S2 can only be supplied with a SELV/PELV power supply.
Page 36
II 3D (1G) Ex tc [ia IIC Ga] IIIC T90 °C Dc 3(2)D Ex tc [ia Db] IIIC T90 Dc; 1410S2B: II 3(1G) D Ex tc [ia IIC Ga] IIIC T90 Dc, II 3(2)D Ex tc [ia Db] IIIC T90 Dc; Emerson.com...
Page 37
June 2023 Quick Start Guide (-40°C ≤ Ta ≤ 65°C) Temperature code: Special Conditions for Safe Use (X): 1. Installation “ic”, Um Has been defined as 30Vdc. The 1410S2 can only be supplied with a SELV/PELV power supply. 2. The 1410S2 does not pass the 500Vac requirement from the IS outputs to Earth (IEC/EN 60079-11, clause 6.3.13).
Page 38
≤ +65°C) ABNT NBR IEC 60079-0: 2013, ABNT NBR IEC Standards 60079-7:2008, ABNT NBR IEC 60079-11: 2013, ABNT NBR IEC 60079-15:2012, ABNT NBR IEC 60079-31:2014 Special Conditions for Safe Use (X): See Certificate for Specific Conditions for Safe Use. Emerson.com...
Page 39
June 2023 Quick Start Guide 7.2.9 Japan N4 – CML Increased Safety with Intrinsically Safe Outputs to Zone Certificate CML20JPN3241X Ex ec [ia Ga] IIC T4 Gc (-40°C ≤ T ≤ +65°C), Ex ec nA [ia 1410S2A Ga] IIC T4 Gc (For use only with the Cisco Outdoor Access Point Model IW-6300H-AC-x-K9) Special Conditions for Safe Use (X):...
Page 40
Ex ec [ic] IIC T4 Gc, Ex ec [ic IIIC Dc] IIC T4 Gc, Ex tc 1410S2B [ic IIC Gc] IIIC T90 Dc, Ex tc [ic] IIIC T90 Dc (-40°C ≤ T ≤ 65°C) Temperature code Special Conditions for Safe Use (X): See Certificate for Specific Conditions for Safe Use. Emerson.com...
June 2023 Quick Start Guide 8 Declaration of Conformity Quick Start Guide...
Page 42
Quick Start Guide June 2023 Emerson.com...
Page 43
June 2023 Quick Start Guide Quick Start Guide...
Page 44
Quick Start Guide June 2023 Emerson.com...
Page 45
June 2023 Quick Start Guide Quick Start Guide...
Page 46
Quick Start Guide June 2023 Emerson.com...
Page 47
June 2023 Quick Start Guide Quick Start Guide...
Page 48
2023 Emerson. All rights reserved. Emerson Terms and Conditions of Sale are available upon request. The Emerson logo is a trademark and service mark of Emerson Electric Co. Rosemount is a mark of one of the Emerson family of companies. All other marks are the property of their respective owners.
