Summary of Contents for LIFE home integration RG1 DL
- Page 1 RG1 DL RG1 UNI DL CONTROL UNIT FOR AUTOMATIONS FITTED WITH 230 V MOTORS INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCE. VERSIONE 1DP093 - 12/2008...
- Page 2 STANDARD INSTALLATION Components and devices of a typical automation. 5RI122000 2AS3710000...
- Page 3 EXIT 24 Vac 200 mA max 230 Vac 25W max FLASHING 230 Vac 40W max COUTESY LYGHT 230 Vac RG1 DL 0 16 24 230V 24 Vdc 3w max 230 Vdc 40w max RG1 UNI DL ELECTRICAL SYSTEM 0 16 24...
- Page 4 PROGRAMMING THE CONTROL UNIT STOP PLATES STOP PLATES Ensure that the open and close stop plates are set to the correct position Ensure that the open and close stop plates are set to the correct position Ensure gate is in central position (half open) and Ensure gate is in central position (half open) and DEFINING THE STOP PLATES SINGLE MOTOR -...
-
Page 5: Wiring And Connections
WIRING AND CONNECTIONS • Before commencing wiring and connection work, read the SAFETY INSTRUCTIONS AND WARNINGS and INSTALLATION INSTRUCTIONS AND WARNINGS chaps carefully. • All wiring and connection operations must be carried out with the control unit disconnected from the electricity supply. If the disconnection device is not in view, display a sign reading: “ATTENTION: MAINTENANCE WORK IN PROGRESS”. - Page 6 1.1.1 Control unit wiring diagram of the lower part Terminals Description COMMON ELECTRONIC AND AUXILIARY POWER SUPPLY BLACK CABLE GEAR MOTOR RELEASE SWITCH WHITE CABLE ORANGE CABLE BLACK CABLE STOP PLATE and ENCODER RED CABLE COMMON CLOCKWISE ROTATION BLACK 230Vac MOTOR OUTPUT COMMON DARK BLUE GREEN...
- Page 7 List of electric cables The cables needed may vary depending on the installation and type and quantity of devices installed. The cables used in the installation must be IEC 60335 compliant. Connection Pos. Type of cable Electricity supply line 3x1,5 mm cable Power supply Cable supplied with Schuko socket...
- Page 8 DELETING RADIO CONTROL TRANSMITTERS RADIO CONTROL MANAGEMENT The control unit is fitted with a built-in radio receiver with a 1 channel 1000-code memory, with a 433.92 MHz frequency with LIFE Rolling Code and Auto code encoding. Resetting an initialised radio control DELETING A SINGLE RADIO TRANSMITTER DELETING A SINGLE RADIO TRANSMITTER •...
- Page 9 3.1.2 Automatic reclosure Automatic reclosure is activated after a preset PAUSE TIME. In this mode, by pressing the ‘STEP’ key, the automation changes its motion according to the sequence 1 – OPEN 2 – PAUSE 3 – CLOSE 4 - PAUSE; for example, if the automation is opening and one selects the step command on the remote control, the automation stops in pause;...
- Page 10 • • Press the force button (bottom left) and the Press the force button (bottom left) and the FORCE FORCE left red led switches on. left red led switches on. 3.2.3 Force • • Press the + and - buttons to set the force Press the + and - buttons to set the force values.
-
Page 11: Troubleshooting
TROUBLESHOOTING This chapter describes the most frequently encountered problems with the solutions for resolving them. In certain cases, it is explicitly envisaged that operations be performed by a professional fitter: these indications must be followed in order to avoid exposing oneself to serious risks. Malfunctions indicated on the control unit The malfunctions detected by the control unit are indicated through the lighting of the 5 LEDs on the display. -
Page 12: General Information
SAFETY INSTRUCTIONS AND WARNINGS chapter. With the aim of improving its products, LIFE home integration reserves the right to bring about alterations to them at any time, without giving prior notice. This document conforms to the state of the automation at which it is provided when released for sale. -
Page 13: First Usage
TESTING AND TRIAL RUN The testing and trial run must be performed by a COMPETENT PERSON supervised and aided by a PROFESSIONAL FITTER. It is the responsibility of the person who tests and sets up • the automation (of which the control unit is a part) to perform the checks required in accordance with the risks existing and to check conformity with the relevant legislation and standards, in particular with EN standard 12445, which governs the methods for performing trials on gate automations and EN standard 12453 that specifies the performance requisites concerning safety of use. -
Page 14: Routine Maintenance
MAINTENANCE 10.1 Maintenance instructions and warnings Once the automation has been tested, the parameters set must not be altered. If further adjustments (e.g. alterations to the voltage value) are made, ALL THE CHECKS REQUIRED FOR • TESTING AND COMPLIANCE WITH STANDARDS MUST BE REPEATED. The Manufacturer declines responsibility for damage or injury caused by non-compliance with the information provided in this manual and the safety instructions provided below. -
Page 15: Declaration Of Conformity
Directive 98/37/EC, appendix II, part B (Manufacturer’s Declaration of CE Conformity) LIFE Home Integration Via 1 Maggio, 37 31043 FONTANELLE (TV) – Italy declares that the following product: RG1 DL control unit satisfies the essential requisites established in the following directives: • Low voltage directive 73/23/EEC and subsequent amendments, •...
