Controller
General Purpose Controller 10 LSB
RPN
● All Notes Off (Controller number 123)
Status 2nd byte
BnH 7BH
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When All Notes Off is received, all notes on the corresponding channel will be
turned off. However, if Hold 1 or Sostenuto is ON, the sound will be continued
until these are turned off.
* Not valid if the patch algorithm is Processor Type 1 or Processor Type 2.
● OMNI OFF (Controller number 124)
Status 2nd byte
BnH 7CH
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
* Not valid if the patch algorithm is Processor Type 1 or Processor Type 2.
● OMNI ON (Controller number 125)
Status 2nd byte
BnH 7DH
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
OMNI ON will not be turned on.
* Not valid if the patch algorithm is Processor Type 1 or Processor Type 2.
● MONO (Controller number 126)
Status 2nd byte
BnH 7EH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = mono number: 00H - 10H (0 - 16)
* The same processing will be carried out as when All Notes Off is received.
* Not valid if the patch algorithm is Processor Type 1 or Processor Type 2.
● POLY (Controller number 127)
Status 2nd byte
BnH 7FH
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
* Not valid if the patch algorithm is Processor Type 1 or Processor Type 2.
Reset value
0 (min) * for V-Synth only
unset; previously set data will not
change
3rd byte
00H
3rd byte
00H
3rd byte
00H
3rd byte
mmH
3rd byte
00H
■ System Realtime Message
● Active Sensing
Status
FEH
* When Active Sensing is received, the unit will begin monitoring the intervals of
all further messages. While monitoring, if the interval between messages
exceeds 420 ms, the same processing will be carried out as when All Sounds Off,
All Notes Off and Reset All Controllers are received, and message interval
monitoring will be halted.

■ System Exclusive Message

Status Data byte
F0H iiH, ddH, ......, eeH
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer
whose Exclusive message this is. Roland's manufacturer ID is
41H. ID numbers 7EH and 7FH are extensions of the MIDI
standard; Universal
Universal Realtime Messages (7FH).
dd, ..., ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
Of the System Exclusive messages received by this device, the Universal Non-
realtime messages and the Universal Realtime messages and the Data Request
(RQ1) messages and the Data Set (DT1) messages will be set automatically.
● Universal Non-realtime System Exclusive
Messages
❍ Identity Request Message
Status Data byte
F0H 7EH, dev, 06H, 01H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH, 7FH)
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When this message is received, Identity Reply message (p. 6) will be
transmitted.
VC-2 MIDI Implementation
Status
F7H
Non-realtime Messages (7EH)
Status
F7H
and
3
