ProScan ELITE PELTDV1029 User Manual page 7

：Press it to open the unit and put the disc on the loading tray.
To record if recording function turned on.
Long press 2-3 seconds,screen will light up and pictures will show up until the
interface page.
a screenshot.
Press +/- to adjust volume.
TYPE-C USB port: For both power supply input and connecting with PC(For thelatter,
after connecting the USB cable with PC, select Settings-> Connected Devices->USB
->Use USB for File Transfer.)
To connect external earphone.
To restart the system if abnormal situation happens and the device can't be
Camera: 2 Million pixel, for camera use.
Pull it out to put the device on the table.
Camera
to insert a micro SD per instruction.
TYPE-C USB PORT
Micro SD
Earphone
Reset
05
Bracket
