- Page 1 ULTR A SERIES G7-S52...
-
Page 3: Warranty
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and Inspect Frame Bi-Annually passage around MATRIX strength equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs. Clean Machine As Needed... -
Page 4: Installation
It is recommended that all users of MATRIX exercise equipment be informed of the following information prior to its use. DEATH OR SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. -
Page 5: Back Extension
BACK EXTENSION BACK EXTENSION Align hips with orange pivot and adjust back pad to a comfortable start position... - Page 6 4MM L-Shaped Allen Wrench Phillips Screwdriver 5MM L-Shaped Allen Wrench 8MM Open-End Wrench 6MM L-Shaped Allen Wrench 17MM Open-End Wrench 8MM L-Shaped Allen Wrench Guide Rod Lubrication If any items are missing please contact your country’s local MATRIX dealer for assistance.
- Page 7 Do not fully tighten frame connectors until Be sure to remove the insulating sheet Step 1 Hardware Step 2 Hardware when installing the rep counter. assembly is complete. Vibra-Tite 135 Red Gel Description Description or equivalent must be used on all fasteners Bolt (M10x80L) Bolt (M10x80L) that are not assembled with Nyloc Nuts.
- Page 8 Step 3 Hardware Step 4 Hardware Description Description Washer (Φ10.2xΦ25) Bolt (M10x80L) Nyloc Nut (M10) Spring Washer (M10) Bolt (M10x130L) Washer (Φ10.2xΦ25) Arc Washer (M10) Nyloc Nut (M10) Bolt (M10x25L) Bolt (M10x15L) Washer (Φ35) Washer (Φ10.2xΦ19.0) Bolt (M8x25L) Screw (M5x10L) Washer (Φ8.4xΦ15.5) Bolt (M10x30L) Bolt (M10x55L)
- Page 9 Step 5 Hardware ASSEMBLY COMPLETE! Description Washer (Φ10.2xΦ25) Bolt (M8x25L) Washer (Φ60) Screw (M6x4L) Bolt (M10x25L) Machine Sensor Locations* G7-S13 Chest Press G7-S23 Shoulder Press G7-S71 Leg Extension G7-S72 Seated Leg Curl G7-S70 Leg Press G7-S33 Lat Pull-down G7-S42 Triceps Press G7-S34 Seated Row G7-S40...
- Page 12 G7-S52 Part # 1000402632 © 2018 Johnson Health Tech Rev 1.0 A...
