Thank you, and congratulations on your choice of the Roland KD-80 V-Kick Trigger.
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" (p. 3–4) and
"IMPORTANT NOTES" (p. 4). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner's manual should be read in its entirety. The manual should be
saved and kept on hand as a convenient reference.
Before using the KD-80, you need to make the following settings.
Contents of the Package
KD-80 (pad unit)
Stay
* This package does not include a kick pedal. Use with a commercially available kick pedal installed on the KD-80.
Please be aware that by using a felt beater, you risk causing damage to the head as a result of the metal portions of
the beater that can become exposed when the felt wears thin.
Names of Conponents
Output Jack
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
02892967
'03-5-3N
Owner's Manual
Head tension adjustment (p. 5)
Settings for the percussion sound module (p. 2)
Frame
T-Bolt
Leg
Bracket
Leg x 2
Beater
Connection Cable
Tuning Key
Owner's Manual (this manual)
Tuning Bolt
Stay
Hoop
Head
Cusion
Sensor
Stand
Foot
Rubber Foot
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roland KD-80
Summary of Contents for Roland KD-80
-
Page 1: Contents Of The Package
