- Page 1 HAND-HELD WELDING HEAD MH-5B OPERATION MANUAL S06M0436E-04...
-
Page 2: Table Of Contents
Thank you for purchasing the Amada Miyachi Hand-held Welding Head MH-5B. Before using this Welding Head, read this operation Manual carefully until you have familiarized yourself with it. After reading, keep the manual in a place where operators can refer to it at any time. -
Page 3: For Correct Use
[1] For Correct Use Safety Precautions Before using, read “Safety precau- Denotes operations and practices that may tions” carefully to understand the result in personal injury or damage to the correct method of use. equipment if not correctly followed. ・ These precautions are shown for safe use of our products and for preven tion... - Page 4 Do not use a damaged power cable, connecting cable or plug. A damaged cable or a plug can cause electric shock, short circuits and fire. If any part needs to be repaired, consult Amada Miyachi Co., Ltd. or your distributor.
- Page 5 Do not splash water on the Welding Head. Water splashed over the electric parts, can cause electric shock and short circuits. Keep combustible matter away from the Equipment Spatter can ignite combustible matter. If it is impossible to remove all combustible matter, cover them with non-combustible material.
-
Page 6: Features
[2] Features The Amada Miyachi Hand-held Welding Head MH-5B has the following features. ince the electrode force can be adjusted steplessly, it can be set finely. ・ S Since a stable force is applied to the electrode for each weld , constant weld ・... -
Page 7: Connection To Welding Transformer And Welding Power Supply
Weld force scale ④ Indicates the approximate force exerted. ⑤ Body Be sure to hold the Body to use this Welding Head. Handle with care the metal ⑥ Cover parts the secondary cable ①②③ because they get hot. Do not place ⑦... -
Page 8: User's Maintenance
[6] User's Maintenance 1. Replacing electrode When replacing the electrode, observe the following procedures: If a welding current flows during electrode replacement, injury or breakage may result. When replacing the electrode, be sure to turn off power supply of the welding controller. Loosen the fixing screw and pull out the ①... -
Page 9: Outline Drawing
[7] Outline Drawing - 7 -...
