Panasonic RG-T810LHA Service Manual

Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
We suggest to handle such parts after the static electricity prevention.
It is forbidden to touch the PCB parts by bare hands during the repairing process.
CONTENTS
1.Specifications---------------------------------------------------------------------------------------
2.Parts Identification----------------------------------------------------------------------------------
3.Wiring Diagram---------------------------------------------------------------------------------------
4.Parts List-----------------------------------------------------------------------------------------------
RG-T810LHA
WARNING
IMPORTANT SAFETY NOTICE
PESMX2211005CE
Version:2201
Ventilating Fan
(North America
Market)
PAGE
1
2~4
5
6, 7
