  • Page 1 DRYER USER INSTRUCTIONS GTN 48267 GCHB www.grundig.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 6. Operating your machine 1. Please read this user manual 6.1 Control Panel ......20 first! 6.2 Screen symbols ......20 6.3 Preparing the Machine .....21 2. Important safety and 6.4 Program selection .....21 environmental instructions ...5 6.5 Main programs ......21 6.6 Additional programs ....21 2.1 General safety ......5 6.7 Program selection and...

  • Page 4: Please Read This User Manual First

    1. Please read this user manual first! Dear Customer, Thank you for preferring an Grundig product. We hope that your product which has been manufactured with high quality and technology will give you the best results. We advise you to read through this manual and the other accompanying documentation carefully before using your product and keep it for future reference.

  • Page 5: Important Safety And Environmental Instructions

    2. Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 2.1 General safety • The dryer can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack experience and knowledge provided that they are supervised or trained on the safe usage...

  • Page 6: Electrical Safety

    2.1.1 Electrical safety Electrical safety instructions should be followed while electrical connection is made during the installation. The appliance must not be supplied through an external switching device, such as a timer,or connected to a circuit that is regularly switched on and off by utility. •...

  • Page 7: Product Safety

    2.1.2 Product safety Superheating of the clothes inside of the dryer can occur if you cancel the programme or in the event of a power failure whilst the dryer is running, this concentration of heat can cause self-combustion and fire so always activate the ventilation programme to cool down or quickly remove all laundry from the dryer in order to hang them up and dissipate the heat.
  • Page 8 • You must provide enough ventilation in order to prevent gases exiting from devices operating with other types of fuels including the naked flame from accumulating in the room due to the back fire effect. Underwear that contains metal reinforcements should not be dried in the dryer.

  • Page 9: Mounting Over A Washing Machine

    2.2 Mounting over a washing machine • A fixing device should be used between the two machines when installing the dryer above a washing machine. The fitting device must be installed by the authorized service agent. • Total weight of the washing machine and the dryer -with full load- when they are placed on top of each other reaches to approx.

  • Page 10: Child Safety

    2.4 Child safety • Packaging materials are dangerous for the children. Keep packaging materials away from children. • Electrical products are dangerous for the children. Keep children away from the product when it is operating. Do not let them tamper with the dryer. Use the child-proof lock in order to prevent the children to tamper with the dryer.

  • Page 11: Technical Specifications

    2.8 Technical Specifications Height (Min. / Max.) 84,6 cm / 86,6 cm* Width 59,5 cm Depth 59,8 cm Capacity (max.) 8 kg ** Net weight (plastic front door usage) 48,5 kg Net weight (glass front door usage) 51 kg Voltage Rated power input See type label*** Model code...

  • Page 12: Your Dryer

    3. Your Dryer 3.1 Overview 1. Top panel 2. Control panel 3. Loading door 4. Kick plate opening button 5. Ventilation grids 6. Adjustable feet 7. Kick plate 8. Type label 9. Lint filter 10. Water tank drawer 11. Power cord...

  • Page 13: Package Contents

    3.2 Package Contents 1. Water drain hose * 2. Filter drawer spare sponge* 3. User Manual 4. Drying basket* 5. Drying basket user manual* *It can be supplied with your machine depending on its model.

  • Page 14: Installation

    4. Installation block the opening of the loading door in the place where your Before the calling the nearest dryer is to be installed. Authorized Service for the • Once the dryer is installed, it installation of the dryer, ensure that should stay at the same place electrical installation and water drain where its connections have been...

  • Page 15: Under Counter Installation

    4.4 Connecting to the drain safety assembly. In products equipped with condenser unit, water accumulates in the water tank during the drying cycle. You should drain accumulated water after each drying cycle. You can directly drain accumulated water through the water drain hose supplied with the product instead of periodically draining the water collected in the water tank.

  • Page 16: Adjusting The Feet

    4.6 Electrical connection Hose connection should For specific instructions for be made in a safe manner. electrical connection required during Your drain house will be installation (see 2.1.1 Electrical flooded if the hose comes Safety) out of its housing during water discharge.

  • Page 17: Warnings About Sounds

    4.8 Warnings about sounds 4.9 Changing the illumination lamp It is normal to hear a In case an illumination lamp is used metallic noise from the in your laundry dryer.To change compressor sometimes the Bulb/LED used for illumination during operation. of your tumble dryer, call your Authorized Service.

  • Page 18: Preparation

    5. Preparation 5.1 Laundry suitable for drying in the dryer Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are suitable for drying in a dryer and make sure that you select the appropriate programme. LAUNDRY DRYING SYMBOLS Drying Suitable for...

  • Page 19: Correct Load Capacity

    • Follow the instructions in the It is not recommended user manual for programme to load the dryer with selection. laundry exceeding the level • Do not open the loading door indicated in the figure. of the machine during drying Drying performance will unless necessary.

  • Page 20: Operating Your Machine

    6. Operating your machine 6.1 Control Panel 1. On/Off/Cancel button 2. Program Number Indicator 3. Display 4. Start/Stand-by Button 5. Delay Setting Selection Button 6. Wrinkle Prevention Selection Button / Menu Entry Button 7. Dryness Level Setting Selection Button 8. HomeWhiz Button 9.

  • Page 21: Preparing The Machine

    6.3 Preparing the Machine For detailed program Plug the machine. information, see “Program Place laundry into the machine. selection and consumption Press On/Off/Cancel button for 1 chart”.. second (long). When your machine is turned on 6.5 Main programs for the first time, it turns on with The following main programs are the declaration program (cotton available depending on fabric type.
  • Page 22 To get better results from The wool drying cycle of drying machine programs, this machine has been your laundry should be approved by The Woolmark washed with suitable Company for the drying of program in your washing machine washable wool machine and wrung with products provided that recommended wringing...
  • Page 23 • Timer programs You may select 10 min, 20 min, 30 min, 40 min, 50 min, 60 min, 80 min, 100 min, 120 min, 140 min ve 160 min Timer programs to achieve the required end drying level at low temperatures.

  • Page 24: Program Selection And Consumption Chart

    6.7 Program selection and consumption chart Approximate Spin speed Durйe de Capacity amount of RapiDry Programme in washing sйchage (kg) remaining (minutes) machine (rpm) (minutes) humidity Cottons / Coloreds Extra dry 1000 % 60 Cupboard dry 8 / 4 1000 % 60 152 / 95 Iron dry...

  • Page 25: Auxiliary Functions

    6.8 Auxiliary functions Anti-creasing 0’ Dryness settings selection Dryness settings button is used for adjusting to desired dryness. Program time may change depending on the selection. Anti-creasing 30’ You can activate this function only prior to start of program. Anti-creasing 60’ Drying level slight damp Anti-creasing 120’...
  • Page 26 You may select Lower, Upper 1 Settings and Upper 2 brightness levels by pressing the HomeWhiz button on the brightness setting menu. When the program is completed with audio warning level setting menu, an During the 3 seconds while the error occurs etc.

  • Page 27: Fast Drying

    6.9 Fast Drying Spin 1200 You can shorten the drying time of your clothes with the fast drying feature. This feature is available on all programs highlighted in blue on the control panel. Cotton Cupboard Dry “Fast” button is used to activate. For example, the time required for drying in the Cotton Cupboard Setup program drops from 2:32 to 1:55...
  • Page 28 Water tank Delay Setting When the program is completed, the You can delay the end time of the warning symbol to empty the water program up to 24 hours with the Delay Setting function. tank turns on. If the water tank fills up while the Open the loading door and place the program continues, the warning laundry.

  • Page 29: Starting The Program

    6.13 Child Lock Changing the delay time If you want to change the duration The machine has a child lock which during the countdown: prevents the program flow from Press the On/Off/Cancel button for 3 being interrupted when the buttons seconds to cancel the program.

  • Page 30: Changing The Program After It Is Started

    6.14 Changing the program after Adding or removing laundry it is started during drying may be You can change the program you repeated as many times as selected to dry your laundry with a you wish. But this operation different program after the machine continuously interrupts the starts running.

  • Page 31: End Of Program

    6.16 End of program When the program has ended, Fibre Filter Cleaning and Water Tank warning symbols are illuminated on the program monitoring indicator and “Program Ended” message is displayed on the screen. Loading cover can be opened and machine is ready for another operation.

  • Page 32: Drying Rack

    6.17 Drying Rack...
  • Page 33 General Appearance of the Basket Jumper Trouser Skirt Sneaker Glove...
  • Page 34 Placing the Basket in the Basket: In the laundry placement in the Wool Program in the Basket: basket section, sweaters, pants, Wool Program in Basket allows skirts, sneakers and gloves you to dry your pants, skirts, wool placement are described. Before sweaters and sneakers without placing the sneakers in the basket, spinning in the drum thanks to a...
  • Page 35 Recommended Loads and Drying Durations: The provided rates are guidance rates. If required, initiate additional drying. Recommended Loads and Drying Durations: The provided rates are guidance rates. If required, initiate additional drying. Programme Load Type duration (min.) Wool Sweater 120 - 140 Pants 140 - 160 Accessories such as...

  • Page 36: Homewhiz Function

    7 HomeWhiz function HomeWhiz function allows you to remotely control and monitor your machine with your smart device. With HomeWhiz app you can download your smart device from the 4. When you go to the Settings application store, you can remotely menu, Find HomeWhiz Setup control your machine and choose the using the keys to the right and...
  • Page 37 7. While establishing a connection, 3. You can turn it on and off by pressing HomeWhiz button. the connection symbol flash and “Connecting ...” appear on the screen. When the connection is established, the connection symbol sis lit up continuously and “Connected” appears on the screen.

  • Page 38: Usage Of Homewhiz Function

    7.2 Usage of HomeWhiz Function: Your machine sends you notifications via HomeWhiz app when the To remotely control your HomeWhiz following occurs. You can set setup, Ensure that your machine where you want to receive these is turned on and the door is closed notifications from the settings page and you must activate the function of your machine.
  • Page 39 You can use the HomeWhiz You can also request the function on more than one smart ownership of the machine device. You need to download the from the “user association HomeWhizapplication from the settings” section of the application store of the devices you machine’s settings page.

  • Page 40: Troubleshooting

    7.3 Troubleshooting Follow the steps below if you have a problem with remote control / monitoring or connection. 1. Ensure that your smart device is connected to the internet. 2. Close and reopen HomeWhiz app. 3. Disable the wireless connection setting, enable it again, and reconnect to your machine through the application.

  • Page 41: Maintenance And Cleaning

    8. Maintenance and • A layer can build up on the filter pores that can cause clogging cleaning of the filter after using the dryer for a while. Wash the lint filter Service life of product extends and with warm water to remove the frequently experienced problems will layer that builds up on the lint be reduced if it is cleaned at regular...

  • Page 42: Cleaning The Sensor

    8.2 Cleaning the sensor Never remove the water There are dampness sensors in the tank when the program is dryer that detect whether the laundry running! is dry or not. If you forget to drain the water tank, To clean the sensors: the machine will stop during the •...

  • Page 43: Cleaning The Filter Drawer

    8.4 Cleaning the filter drawer • Open the filter drawer by Lint and fiber that could not be pressing the red button. captured by the lint filter are blocked in the filter drawer behind the kick plate. Clean the filter periodically when there is visible air collection on it or when the symbol lights up, if there is a filter drawer cleaning...

  • Page 44: Cleaning The Evaporator

    • Close the kick plate cover. Please place the sponge carefully inside the frame of the filter cassette shown by arrows in order to avoid squeezing when filter drawer closed”.: Drying without the filter drawer sponge in place will damage the machine! A dirty lint filter and filter drawer will cause longer •...

  • Page 45: Troubleshooting

    9. Troubleshooting Drying process takes too much time. • Pores of the lint filter are clogged. >>> Wash the lint filter with warm water. • Filter drawer may be blocked>>>clean the foam inside the filter drawer. • Ventilation grids on the front side of the machine are blocked. >>> Remove the objects (if any) that block ventilation in front of the ventilation grids.
  • Page 46 Laundry has shrunk, become felted or deteriorated. • A programme suitable for the laundry type is not used. >>> Check the garment tag and select a programme suitable for the fabric type. Drum lighting does not turn on. (On models with lamp) •...

  • Page 47: Electrical Connection

    10.Electrical store. In order to avoid hazards, damaged Connection supply cord should be replaced by the manufacturer, its service agent or Make sure that you have an earthed similarly qualified people. power outlet socket rated at 13 amps A Do not operate without the top cover (minimum).
  • Page 48 PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 392/2012 GRUNDIG Supplier name or trademark GTN 48267 GCHB Model name Rated capacity (kg) Air Vented Type of Tumble Dryer Condenser A+++ Energy efficiency class Annual Energy Consumption (kWh) Automatic Type of Control...
  • Page 49 Repairs necessary as a direct or indirect result of: Accidental damage, misuse or abuse of a product. An attempted repair of a product by anyone other than a Grundig Approved Engineer (the “Engineer”). Installation or use of a product where such installation or use fails to meet the requirements contained in this guarantee or the User Instructions Booklet.
  • Page 50 Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only. Does Grundig offer replacements? This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model, but when this is not possible, a model of similar specification will be provided.
  • Page 51 Will there be any charge for the repairs? It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if: ...
  • Page 52 Should you experience any difficulty in obtaining service contact the Grundig Customer Helpline on Tel: 0333 207 9920 or e-mail: customerservice@support.grundig.co.uk...
