The two Dante receiver (input) channels associated
with the Model 373A's audio inputs also need to be
routed to the Dante transmitter (output) channels pro-
vided by the desired source device. These two audio
signals can be sent to the Model 373A's 2-channel
headphone output.
The Model 373A supports an audio sample rate of
48 kHz with no pull-up/pull-down values available.
The Model 373A can serve as the Leader clock for
a Dante network, but in most cases it will be config-
ured to "sync" to another device that is serving as the
"grand Leader" for the Dante implementation.
The Model 373A has a default Dante device name
of ST-M373A- followed by a unique suffix. The suf-
fix identifies the specific Model 373A that is being
configured. The suffix's actual alpha and/or numeric
characters relate to the MAC address of the unit's
Ultimo integrated circuit. The one Dante transmitter
(output) channel has a default name of Ch1. The two
Dante receiver (input) channels have default names of
Ch1 and Ch2. Using the Dante Controller application
the default device name and channel names can be
revised as appropriate for the specific application.

Model 373A Configuration

Many of the Model 373A's operating parameters can
be configured to match the needs of specific applica-
tions. The STcontroller software application is used
to observe a unit's current configuration and perform
any changes that are required. No DIP switch settings
or other local actions are used to configure the unit.
This makes it imperative that the STcontroller software
application be available for use in a personal computer
that's connected to the related LAN.
STcontroller is available free of charge on the Studio
Technologies' website (studio-tech.com/stcontroller)
and is compatible with personal computers running
Windows
and macOS
®
®
sary, download and install STcontroller onto a des-
ignated personal computer. This personal computer
must be on the same local area network (LAN) and
subnet as the Model 373A unit or units that are to be
configured.
Model 373A User Guide
Studio Technologies, Inc.
Model 373A
INTERCOM BELTPACK
operating systems. If neces-
Changes made using STcontroller will be immediately
reflected in the unit's operation; no Model 373A "re-
boot" is required. Each time a change is made the talk
button, located on the top panel, will momentarily flash
orange to indicate that a command from STcontroller
has been received.
Issue 2. June 2023
Page 9
