Back panel

# Feature
External antenna
1
DC IN jack
2
AUDIO IN/OUT jacks
3
HUB STATUS switch
4
8
1 2
Description
Receives signals from external senders. Sends signals to external receivers.
Plug the AC adapter into this jack.
When used as a sender, plug an external audio source into the AUDIO IN jack.
When used as a receiver, plug your speaker system into the AUDIO OUT jack. Please note, this
device operates as either a sender and/or receiver, so you can use it simultaneously to send and
receive on your Rocketboost network.
Enables/disables hub mode operation. Please see the "Establishing communication" section on
page 21 for more information.
