RocketFish RF-RBWS02 User Manual

Wireless outdoor speaker
Hide thumbs Also See for RF-RBWS02:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Wireless Outdoor Speaker
RF-RBWS02
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-RBWS02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RocketFish RF-RBWS02

Summary of Contents for RocketFish RF-RBWS02

  • Page 1 Wireless Outdoor Speaker RF-RBWS02 User Guide...

  • Page 2: Table Of Contents

    Legal notices ...28 One-year limited warranty ...31 Introduction Congratulations on your purchase of a Rocketfish Wireless Outdoor Speaker Kit that is part of the Rocketboost™ system. The Rocketboost system implements an expandable Wireless Audio distribution technology which is compatible with all Rocketboost products. All Rocketboost products use a proprietary 2.4GHz communication...

  • Page 3: Important Safety Instructions

    The speaker operates on eight batteries or from a wall socket using an AC adapter, and offers you rich sounding bass and crisp treble. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK: DO NOT REMOVE SCREWS, COVERS OR THE CABINENT.
  • Page 4 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
  • Page 5 Manager POWER /JOIN BASS CHARGE CHANNEL L - MONO - R SOURCE RF-RBWS02...

  • Page 6: Features

    • 2-in-1 power/join control combines controls into one easy-to-use package • Built-in charger for recharging the optional NiMH rechargeable batteries Package contents Examine the contents of the box for your wireless speaker kit. The box should contain: • Wireless sender/receiver • Wireless speaker •...

  • Page 7: Front Panel

    Press the Source button to find the next available source. Sender-mode LED Turns blue when sending signals. Note: This LED will light automatically when a 3.5 mm connector is attached to the unit, as the device senses the cable connection. RF-RBWS02...

  • Page 8: Back Panel

    When used as a sender, plug an external audio source into the AUDIO IN jack. When used as a receiver, plug your speaker system into the AUDIO OUT jack. Please note, this device operates as either a sender and/or receiver, so you can use it simultaneously to send and receive on your Rocketboost network.
  • Page 9 SOURCE Description Turn this knob to increase or decrease the volume. Press to turn the speaker on, then hold to initiate joining. Press again to go to standby. Press to select an audio source from one of the connected sources.
  • Page 10 Feature Channel MONO (L/R) indicators Audio source signal indicator Lights when there is an active link and the speaker receives audio signals from Wireless speaker - back BASS 15V DC Feature BASS button DC IN jack Description If two wireless outdoor speakers are connected to the sender, left lights when the left audio channel is on and right lights when the right audio channel is on.

  • Page 11: Remote Control

    Press to enable/disable the BASS enhancement. Press to toggle between SPEAKER Input A or Pre-In A of the sender (only applies to RF-RBKIT - purchased separately for the Rocketboost system). Press to toggle between the audio sources connecting SPEAKER Input B or Pre-In B of the sender (only applies to RF-RBKIT - purchased separately for the Rocketboost system).

  • Page 12: Battery Operation

    Plug the other end of the power cord into an AC power outlet. The power indicator on the speaker turns on and goes into standby mode. Battery operation Your Wireless speaker is compatible with either Alkaline or NiMH rechargeable batteries.
  • Page 13 Charging the wireless speaker When the battery power becomes low, the charge indicator light will initially blink, indicating the need to charge the speaker. If it does not receive a charge, the indicator light will eventually go off. Caution: To avoid the risk of fire, and to prevent damage, only use the DC to AC adapter supplied with your wireless speaker kit.
  • Page 14 Speaker back Note: Make sure that the batteries are fully charged for at least 16 hours. This will guarantee a longer operating lifetime for the batteries. The wireless speaker lets you charge when it is powered on or in standby mode.

  • Page 15: Setting Up Your Remote Control

    Remove the insulation sheet before using the remote control for the first time. Aim the remote control at the IR sensor on the front lens from a maximum distance of 23 ft. (7 m) away and the maximum angle of +/- 30 degrees from the center line. RF-RBWS02...
  • Page 16 To replace the battery: Squeeze and pull to release the battery tray. You can remove the battery door with your fingernails by using the spaces set back in the remote control Match the polarity on the lithium cell with a plus sign (+) on the battery tray.

  • Page 17: Using The Remote Control

    3.5mm AUDIO IN jack, it automatically and used as a stereo sender. When the sender/receiver is connected to a power outlet, and a speaker system is attached to the AUDIO OUT jack, the output is always active assuming the RX LED is lit and there is a valid sending device.
  • Page 18 Connecting your wireless sender/receiver When connecting to an audio source • Using the supplied audio cable, connect the AUDIO IN jack of the sender/receiver to the AUDIO OUTPUT jack of your audio device (such as an A/V receiver, PC, or iPod®). (Supplied) To audio output jack, such as a personal music player.

  • Page 19: Adjusting The Antennas

    Connecting to the AC adapter Adjusting the antennas Adjust the two external antennas as far away from the AC adapter, a TV, or other radiation source as possible. Note: Make sure that the device is located at least 18” from any wireless router. RF-RBWS02...
  • Page 20 To adjust the antennas: Pull the antennas up from their stored position. Adjust the antennas for best reception. We recommend that the antennas be oriented vertically for best wireless performance. In some circumstances you might get better range by setting the antennas at a 45°...

  • Page 21: Using Your Outdoor Speaker Kit

    Note: Interference is possible from other devices that operate in the same frequency band. You may have to move the sender and wireless speaker around a bit to find an interference-free location. Make sure your Rocketboost products are at least 18" from any wireless router.
  • Page 22 To use the unit as a sender with another node as the hub (only follow these instructions if you have an existing Rocketboost network. Otherwise skip to the Listening to Music section): Set the HUB STATUS switch to DISABLE. Important: Make sure that the HUB STATUS switch is set to DISABLE before the sender/receiver is turned on.
  • Page 23 Note: When a link is established between the sender/receiver and wireless speaker, and an audio source signal is transmitted from the sender/receiver to the speaker, the SOURCE indicator on the wireless speaker will light solidly blue.
  • Page 24 2). If you are unsure how to do that refer to the instructions above. Tune to the source that you wish to listen to on the first Wireless speaker. Join the second wireless speaker to the network.

  • Page 25: Listening To Music

    Turn on the audio source and your speaker system. Adjust the volume level on your speaker system. Note: When the wireless speaker is employed as left or right speaker, the corresponding Channel MONO L/R indicator lights up. To adjust the balance of two outdoor speakers: •...

  • Page 26: Troubleshooting

    Tx/Rx indicator is blinking when it is muted.) • Make sure that the unit or your receiver's output is connected to the speaker system, which is powered on and working. • Make sure that the Hub Status switch on the sender/receiver is set correctly.

  • Page 27: Specifications

    Problem Connecting a device When trying to change the source on a Rocketfish unit the Power LED flashes 5 times. Specifications Sender Power supply Maximum line-level input signal level Maximum line-level output signal level Output loading Signal-to-noise ratio Dimensions (WxHxD)

  • Page 28: Legal Notices

    Speaker impedance Rated output power (at 10% thd) Dimensions (WxHxD) Weight Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may...
  • Page 29 FCC Rules could void the user’s authority to operate this equipment. Copyright © 2009 Rocketfish. Rocketfish and the Rocketfish logo are trademarks of Best Buy Enterprise Services, Inc. Rocketboost and the Rocketboost logo are trademarks of Best Buy Enterprise Services, Inc. Other brands and product names are trademarks or registered trademarks of their respective holders.

  • Page 31: One-Year Limited Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 32 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 33 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
