3.6
Program Loudmouth
The wireless speaker can be field programmed for any volume level between 05-99% by entering the volume level
as a 2-digit code. Field programming Speaker Volume Level sets both the voice and the pre-announce tone
volume levels. The PC programmer is required for independent programming of the voice and the pre-announce
tone volume.
In our example we will program an LM-U450 for 25% Speaker Volume Level. The Loudmouth
factory with a 50% volume setting.
13
1.
2.
3.
4.
5.
6.
7.
7.
IMPORTANT NOTE:

Checking the Current Volume Setting

To readout the current volume setting, follow the instructions above and enter a
volume setting code "00". When you press the ENTER button the radio will
immediately begin to display the 2-digit volume setting; with each digit separated by
a hyphen.
19
™
Volume
Refer to Section 1.5 - Determine the volume setting
Press and HOLD the PROGRAM button (See
for location). A "P" will appear on the program display as you enter program mode and the
radio will beep rapidly.
Release the PROGRAM button after the beeping has stopped. The radio will emit a triple
beep indicating that the radio is in program mode and a hyphen will appear on the program
display.
Scroll to the character "U" by clicking the PROGRAM button until the program display
shows the correct character. Pause—the radio will sound a low tone and show a hyphen
across the center of the display to indicate that it is ready to accept the first digit of the
volume setting.
st
Enter the 1 digit of the volume setting by clicking the PROGRAM button until the program
display shows the desired number. Pause—the radio will sound a low tone and show a
hyphen across the center of the display to indicate that it is ready to accept the next digit.
nd
Enter the 2 digit of the volume setting by clicking the PROGRAM button until the program
display shows the desired number. Pause—the radio sounds a low tone and will show a
hyphen across the center of the display to indicate that it is ready to accept the next digit.
Press and release the ENTER button to save your programming. A triple beep will sound to
indicate that programming was successful and a hyphen will appear on the program
display. The radio is now ready for another program entry.
NOTE: An error tone will sound if you attempt to save an incorrect code, an "E" will appear
on the display. Check the digits you are attempting to enter, then re-enter.
Once you have made your final program entry, press the ENTER button a final time to exit
programming mode. The Program display will be blank and the radio will be ready for use.
™
The Loudmouth will exit program mode automatically after 30 seconds if no program
entries are attempted.
Volume setting below 10% are entered as a 2-digit code with a first digit "0".
Section 3
and write down the desired volume.
™
Loudmouth
Programming
™
is set from the
receiver assembly on page 2
