Receivers And Pa Speakers - Ritron Jobcom J Series J-U410 Owner's Manual

2.5
Installing multiple Loudmouth
Many locations may require the installation of multiple Loudmouth
and PA speakers are used when:
•
Paging separate buildings is required.
•
The coverage area is too large for a single receiver and PA speaker.
•
Zone paging is required.
•
Paging is required in more than one location.
Zone paging, or paging in more than one location requires a separate
™
Loudmouth
•
With zone paging all radios can operate on the same Loudmouth
•
Each Loudmouth
each zone.
•
The Loudmouth
once, or Group Call* to page more than one zone.
•
Zone paging allows for volume levels that are programmed to the specific needs of that area.
•
If zone paging is not necessary, all Loudmouth
code.
* All Call and Group Call code programming requires the Ritron Loudmouth
Zone 1 – Warehouse and loading dock
• Single Loudmouth receiver with 2 speakers.
• One speaker is located inside the warehouse and the
other is located outside for the loading dock.
• Speaker volume is set to 50% for the warehouse
environment.
Example of Zone paging
11
™
receiver for each area.
™
receiver can be programmed for a unique paging code, allowing selective paging to
™
receivers can be programmed for an All Call* code that allows paging of all zones at
Section 2

receivers and PA speakers

™
receivers and PA speakers. Multiple receivers
™
radio frequency.
™
receivers can be programmed for the same paging
Zone 2 – Cafeteria
• Single Loudmouth receiver with 1 speaker.
• The speaker is located inside the cafeteria area.
• Speaker volume is set to 25% for the restaurant
environment.
Zone 3 – Sales office
• Single Loudmouth receiver with 1 speaker.
• The speaker is located inside the Sales office.
• Speaker volume is set to 10% for the office environment.
Installation
™
PC Programmer.
