2.6

Vehicular installation

™
The Loudmouth receiver can be powered with an optional Ritron model CCL-M cigarette lighter adapter for use in
mobile applications.
•
Route the CCL-M power cord away from the antenna and speaker wires.
When the speaker is mounted on the roof of a vehicle at head
level the volume level should be reduced to 50% or less to
prevent hearing damage.
2.7

Temporary outdoor installation

™
The Loudmouth receiver can be temporarily installed outdoor with the use of weatherproof enclosures.
LMH-100
RSS-100
E9UDVCRN
The Ritron model LMH-100 is a weatherproof, fiberglass reinforced polyester enclosure
designed to house the Loudmouth
connections are routed from the bottom of the enclosure through electrical conduit.
The LMH-100 includes:
•
Dual stainless steel, padlockable latches
•
Nema 3 weatherproof, fiberglass reinforced polyester enclosure
•
Mounting flanges for flat surface
•
Dimensions: 13"H x 10.5"W x 5.5"D
Ritron model RSS-100 10W solar panel kit can be used to power the Loudmouth
receiver without the need for the RPS-1A power supply in locations where AC power is
not available.
The RSS-100 includes:
•
10-Watt solar panel with mounting bracket
•
7AH sealed rechargeable battery
•
Solar charge controller
•
Nema 3 weatherproof, fiberglass enclosure
•
Mounting flanges for flat surface
•
Dimensions: 12"H x 10.25"W x 6.25"D
The RPS-1A power cube can be temporarily plugged into an outdoor outlet with a large
in-use weatherproof cover such as the Carlon
Hardware stores nationwide).
Section 2
™
receiver and antenna. Speaker and power
Weight: 8 lbs.
Weight: 10 lbs.
®
model E9UDVCRN
Installation
CCL-M
™
(available in Lowe's
12
